Seat the FACET into the M.2
sockets.
Keep it in an angle as the next
step explains the SMA antenna
cable routing.
Note:
In case a cellular modem has
been installed, the standoff
adjacent to the USB connector
may collide with the modem -
Remove it
Pay attention to the way the
antenna cables are routed below
the seated FACET.
Note:
In case a cellular modem was
not installed, and the standoff
haven't been removed, Pay
attention to the longer cable, it
should be routed around the
standoff, make sure the FACET
doesn't pinch it when pushed
down.
Before pushing down the FACET
for final assembly, the cables
should be free and loose.
Assemble the RP-SMA
connector with the Cellular
antenna side panel
SIM slot located at the top of the
FACET.
