29-Aug-19
fitlet2 FC-OPLN Installation instructions
Package content
1x FC-OPLN
FACET card
2x Retaining
2x Brass
2x 3mm M3
1x M3 nut
washer
standoff
Phillips screw
4x Phillips
1x 8mm M3
1x Tall side
1x SCG tall
1x Deep bottom
Chassis screws
Phillips screw
panel
side panel
cover
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CompuLab Fitlet FC-OPLN
Summary of Contents for CompuLab Fitlet FC-OPLN
- Page 1 29-Aug-19 fitlet2 FC-OPLN Installation instructions Package content 1x FC-OPLN FACET card 2x Retaining 2x Brass 2x 3mm M3 1x M3 nut washer standoff Phillips screw 4x Phillips 1x 8mm M3 1x Tall side 1x SCG tall 1x Deep bottom Chassis screws Phillips screw panel side panel...
- Page 2 Remove the bottom cover by unscrewing the 4x Phillips chassis screws and pull out the cooling plate gently after removing the 3x Phillips screws. Plug the IPX connectors to the Wifi module as follows: Long cable to port #1 Short cable to port #2 Plug the WiFi module into the M.2 Key-E slot and fasten with the 3mm Phillips screw...
- Page 3 Connect the storage module to the M.2 SATA slot on the FACET. For easier installation, thread 2x retaining washers on the 8mm Philips screw and screw using the hex nut from the other side. The storage module should be seated between the retaining washer an the Phillips screw Install the FACET into the M.2...
- Page 4 Peel the protective tape off the thermal pad and install the bottom cover with the supplied Phillips chassis screws. Hold both tall side panels while screwing the Phillips screws Make sure the heatsink block is aligned with the storage module. Page 4...
