H-4378, H-4379
π
H-4380
Wire utility carts
TOOLS NEEdEd
Rubber Mallet
Figure 1
Figure 2
Figure 3
PAGE 1 OF 2
1-800-295-5510
uline.com
CASTER INSTALLATION
TO INSTALL CASTERS
1.
Make sure post is positioned as shown. (See Figure 1)
2. Engage the wheel brakes to keep casters from rolling during
assembly. Use a rubber mallet to tap caster stems into posts.
(See Figure 1)
INSTRUCTIONS FOR UNIT ASSEMBLY
1.
Start with the lowest shelf. Snap the interlocking pieces of a
shelf support (wide end down) around the post at the lowest
Shelf
groove where shelf is to be located. Slide the support up or
Support
down until it snaps onto the groove. Add a shelf support to the
same place on the remaining posts. (See Figure 2)
NOTE: NSF requires food service applications to keep the
lowest shelf at least 6" above the floor.
2. Slide post through underside of shelf until shelf slides firmly
over supports. (See Figure 3)
1213 IH-4378
