TRANSITION NETWORKS' POCKET SWITCH

TECHNICAL SPECIFICATIONS

Standards
IEEE 802.3, IEEE 802.3u
Dimension
4.75" X 5.75" X 1.0"
(120mm x 146mm x 25mm)
Power Supply
NOTE:
Replace power supply only with the equivalent input rating (see below) and
output rating (regulated 12VDC at 1.5 A).
TN PN
Requirement
3507
240 volts, 50 hertz
3342
230 volts, 50 hertz
3340
120 volts, 60 hertz
3346
100 volts, 50-60 hertz
3511
240 volts, 50 hertz
3537
(with power cord: 3522)
Environment
Temperature:
0-50°C (32° to 122° F )
Humidity
10-90%, non condensing
Altitude
0-10,000 feet
Warranty
Lifetime
29
Location
United Kingdom
Europe
USA/Canada/Mexico
Japan
Australia
South Africa
Transition Networks'
Transition Networks'
Pocket Switch
(E-PSW-TX-02, E-PSW-FX-02)
For assistance in installing, using, or
maintaining the TRANSITION Networks
Pocket Switch, contact TRANSITION
Networks Technical Support
at:
(800) 260-1312
or contact your local distributor.
33015.B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-PSW-TX-02 and is the answer not in the manual?

Questions and answers

Related Manuals for Transition Networks E-PSW-TX-02

Summary of Contents for Transition Networks E-PSW-TX-02

  • Page 1: Technical Specifications

    TRANSITION NETWORKS’ POCKET SWITCH TECHNICAL SPECIFICATIONS Standards IEEE 802.3, IEEE 802.3u Dimension 4.75" X 5.75" X 1.0" (120mm x 146mm x 25mm) Power Supply NOTE: Replace power supply only with the equivalent input rating (see below) and output rating (regulated 12VDC at 1.5 A).
  • Page 2 Copyright Restrictions © 1997 TRANSITION Networks All rights reserved. No part of this work may be reproduced or used in any form or by any means – graphic, electronic, or mechanical – without written permission from TRANSITION Networks.

  • Page 3: Table Of Contents

    1 INTRODUCTION ......1 Transition Networks’ Pocket Switches ....1 Features .

  • Page 4: Introduction

    • The item(s) may be shipped by the customer or the distributor. • Transition Networks will repair or replace the unit, at TN’s discretion, and cover the cost of the return freight to the distributor or to the customer, whichever requested the RMA number.

  • Page 5: The Evolving Ethernet Network

    Warranty Statement A. Five Year Warranty Transition Networks, Inc. (TN) warrants, for a period of five years, that TN products (with the exception of power supplies and fans that TN warrants for two years) will be free from defects in materials and workmanship, and will be in conformity with TN’s specifications.

  • Page 6: Network Flexibility

    (ISO). IEEE 802.3u is the extension of IEEE 802.3 to 100BASE-X. Protocol Compatible As devices functioning on the OSI MAC layer, Transition Networks’ pocket switches are protocol independent and therefore totally compatible with IEEE 802.3, IEEE 802.3u, TCP/IP, NetWare, DECnet and XNS protocols.

  • Page 7: Operation

    4. OPERATION The Transition Networks’ pocket switch requires no operator intervention beyond occasionally monitoring LED status indicators. Power LED Indicator Port 1 LED Indicators POWER Steady green LED indicates connection to external AC power. NOTE: The port LED indicators provide separate data for each port.

  • Page 8: Increasing Bandwidth By Segmenting 10Base-T Collision Domain

    Increasing Bandwidth by Segmenting 10BASE-T Collision Domain The Transition Networks’ pocket switch adapts to the fact that each Ethernet network device (station) is connected independently to the shared Ethernet signaling system, called the network medium. Each station transmits serially over the shared medium to every other attached station.

  • Page 9: Installing Network Cable

    MAC Address Table The dynamic internal routing table of the Transition Networks’ pocket switch provides self learning capabilities for up to 8192 MAC addresses of incoming and outgoing packets. Once a network node address is stored in the MAC address table, data packets addressed to that node are sent directly.

  • Page 10: Doubling Bandwidth By Installing Full-Duplex

    RJ-45 plug connectors installed at both cable ends. 2. Connect male RJ-45 plug connector at one end of 10BASE-T or 100BASE-TX cable to Transition Networks’ pocket switch RJ-45 jack connector. 3. Connect male RJ-45 plug connector at other end of 10BASE-T...
  • Page 11 Pocket Switch 10 Mb/s 100 meters Install Transition Networks' Pocket Switch AND Install Full-Duplex 10BASE-T Card in Server For Collision-Free Full-Duplex Connection to Serve 20 Mb/s 10 Mb/s...

  • Page 12: Increasing Bandwidth Ten-Fold By Installing 100Base-Tx

    Increasing Bandwidth Ten-fold by Installing 100BASE-TX (Fast Ethernet) Fast Ethernet, 100BASE-TX or 100BASE-FX on the Transition Networks’ pocket switch, moves signals at 100 Mb/s, ten times faster than legacy Ethernet. Legacy Ethernet and Fast Ethernet Since 100BASE-TX Fast Ethernet is an extension of the existing Ethernet IEEE 802.3 standard that uses the existing 802.3 media access control...
  • Page 13 5 segments. 4. Repeat steps 1-3 for next collision domain. Transition Networks’ The Transition Networks pocket switch can be installed to provide one 10BASE-T switched port and one 100BASE-TX switched port. Auto-Negotiation The 100BASE-TX standard includes automatic speed and duplex mode sensing as part of the Auto-Negotiation function.

  • Page 14: Increasing Network Distance By Installing 100Base-Fx

    (full-duplex) Restrictions: Optical loss budget NOTE: If the Transition Networks’ pocket switch is installed in a network that is evolving by increments from legacy 10BASE-T Ethernet to 100BASE-TX Fast Ethernet and/or to 100BASE-FX Fast Ethernet, refer again to these cable type restrictions at each upgrade.

  • Page 15: Setting Dip Switch

    Transition Networks’ pocket switch. Existing 100 Mb/s Existing 10 Mb/s Install Install Transition Networks' Pocket Switch AND Install Fiber Cable to Server AND Install 100BASE-TX/100BASE-FX Media Converter at Server OR Install Fiber Card in Server...

  • Page 16: Installation

    (depending upon power configuration in country where installed) User’s Guide 33015 Installing on Flat, Stable Surface The Transition Networks’ pocket switch was designed and built to be installed on a table or shelf. Ensure that the installation location is: • stable •...
