2014/30/EU and 2011/65/EU and conforms with the following standards or normative docu- ments: EN 61010-1, EN 61010-2-010; EN 61326-1, EN 60529 and EN ISO 12100� A copy of the complete EU Declaration of Conformity can be requested at sales@ika�com� Explication of warning symbols /// Symbols used in this instruction manual “Safety instructions”...
Incorrect Indicates incorrect implementation of an action step� Please note Indicates action steps for which particular attention must be paid to a particular detail� Beep Indicates action steps, for which beep sounds are to be heard� Power outage Indicates device restart after a power outage� Internet Indicates action steps for which further information is included in the online www.
Page 8
Before commissioning, read and observe the safety instructions� � Keep the operating instruction manual accessible for all users� � /// Other risks Risk of burning at hot surfaces The top edge of the heating bath can heat up to temperatures above 65 °C during operation� Do not touch hot device components without protective gloves�...
The heating bath is used for tempering media� It is the user’s responsibility to to determine � which medium is tempered� The heating bath is not used for tempering foods� The heating bath is suitable for use with rotary evaporators from IKA� Recommended tempering media › Water (up to 80 °C) ›...
Unpacking /// Unpacking Unpack the device carefully� Any damage should immediately be reported to the carrier (mail, rail or freight forwarding company)� /// Scope of delivery heating bath power cord user guide...
/// Display Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6 Fig. 7 Fig. 8 Fig. 9 Fig. 10 Fig. 11 Operation /// Start-up Observe the ambient conditions (temperature, humidity, etc�) listed under “Technical data”� � The unit is ready for service when the mains plug has been plugged in� �...
Page 13
20...99 °C 20...99 °C 20...99 °C 20...99 °C...
Page 14
/// Setting the target temperature Activate the SET function by turning and pressing the rotating / pressing knob� Set the desired heating bath temperature by turning the rotating / pressing knob� � The LED setpoint temperature will be always on whenever the set temperature is shown� �...
Page 15
20...99 °C 20...99 °C 20...99 °C 20...99 °C /// Setting the operating modes Operating mode A Switch on the device at the mains switch� � The heating function is switched off� � The target value is set to 20 °C� �...
Page 16
Operating mode b Switch on the device at the mains switch� � The heating function is switched off� � The target value is set to 20 °C or the most recent set temperature� � The target value can be adjusted� �...
Page 17
20...99 °C 20...99 °C 20...99 °C 20...99 °C 20...99 °C 20...99 °C /// Safety temperature The safety circuit prevents the temperature of the heating bath from getting too high as a result of controller error� Once the safety temperature has been reached, the device switches off per- manently�...
First, download the latest driver for IKA devices with USB interface from: http://www.ika.com/ika/lws/download/usb-driver.zip Install the driver by running the setup file� Then connect the IKA device to the PC via the USB data cable and follow the instructions� The data communication is via a virtual COM port�...
/// Cleaning: For cleaning disconnect the mains plug! � Use only cleaning agents which have been approved by IKA to clean IKA devices� � These are water (with tenside) and isopropanol� Wear protective gloves during cleaning the devices�...
Error codes The fault is shown by an error code on the display as following if the error occurs� � Proceed as follows in such cases: › Turn off the device by using the main switch� › Carry out corrective measures� ›...
Page 21
Causes › Error in calibration Effect › Heating switched off Solutions › Switch off the device and switch on again Causes › Breakage of the controller sensor Effect › Heating switched off Solutions › Switch off the device and switch on again Causes ›...
Technical data Power supply 200���240 ±10 % Voltage 100���120 ±10 % Frequency 50 / 60 Power input 1450 Power input standby Heating function Heat control Set temperature resolution ± 1 Heating temperature min� ��� max� °C Room temperature ��� 99 Heat output 1400 Controller oscillation (3l water / 90 °C):...
Warranty In accordance with IKA warranty conditions, the warranty period is 24 months� For claims � under the warranty please contact your local dealer� You may also send the device direct to our factory, enclosing the delivery invoice and giving reasons for the claim� You will be liable for freight costs�...
Page 24
VIETNAM IKA Vietnam Company Limited Phone: +84 28 38202142 eMail: sales�lab-vietnam@ika�com Discover and order the fascinating products of IKA online: www.ika.com IKAworldwide IKAworldwide /// #lookattheblue @IKAworldwide Technical specifications may be changed without prior notice�...
