  • Page 1 Babyleo TN500 IncuWarmer Information on verification of the scale Babyleo TN500...
  • Page 2 This page has been left blank intentionally. Information on verification of the scale Babyleo TN500...

  • Page 3: Table Of Contents

    Contents Contents Babyleo TN500 IncuWarmer Use of this documentation ..............Subject to change without notice ............ Copyright and other protected rights ..........Basic safety Information................Compliance with the documentation..........Symbols and product labels............Modifications to the product............Information on verification of the scale ..........

  • Page 4: Use Of This Documentation

    Use of this documentation Use of this documentation This document contains information on the calibration of the scale for the IncuWarmer Babyleo TN500 from version 1.05. Subject to change without notice Dräger reserves the right to modify the product and/or this documentation without prior notice.

  • Page 5: Basic Safety Information

    ► Observe the symbols and product labels. Modifications to the product Modifications to the product may result in malfunctions and subsequently in personal injury (injury or death), property damage, or environmental damage. ► Do not modify the product. Information on verification of the scale Babyleo TN500...

  • Page 6: Information On Verification Of The Scale

    General information The Babyleo TN500 is a heat therapy device for premature babies and neonates. It can be used to warm patients with a body weight of up to 5 kg (11 lbs) and height of up to 55 cm (22 in).

  • Page 7: Scale Function

    No values are displayed if the weight exceeds the weighing range, and the following message is shown: Maximum weight exceeded. Maximum tare weight The following message appears if the maximum tare weight is exceeded: Load is too high for zeroing. Information on verification of the scale Babyleo TN500...

  • Page 8: Geographic Position

    Fig. 13/1 in chapter 3.11 Access to the service menu). Labeling 3.5.1 Device labeling The scale label (2M60669, Fig. 2/1) with information on the scale and the device’s name plate (Fig. 2/2) are located on the rear of the device. Information on verification of the scale Babyleo TN500...
  • Page 9 (2M60660), and the label with the approval number (2M60659) are located on the right side of the weighing module. Fig. 3 Labeling the weighing module The 6 screws for opening the module are secured with seal stickers (Fig. 4). Information on verification of the scale Babyleo TN500...
  • Page 10 These fields are filled out on site as part of the repair. A corresponding comparison can be found in the following table. Factory labeling Repair labeling 2M60657 2M60109 2M60660 2M60684 Information on verification of the scale Babyleo TN500...

  • Page 11: Turning The Device On And Off

    3. Then turn the device on at the front on the control unit with the Start/Stand-by button (Fig. 5/1).  The device performs an automatic self-test. The main page is then displayed. Information on verification of the scale Babyleo TN500...
  • Page 12 If the device is only turned off with the Start/Stand-by button on the control unit, and the power plug is subsequently disconnected, an alarm signal sounds for a few minutes. 5. Pull the power plug. Information on verification of the scale Babyleo TN500...

  • Page 13: Important Instructions For Handling

    – We recommend placing a setting load of 10 kg onto the mattress tray for approx. 10 s three times in succession before calibration. Information on verification of the scale Babyleo TN500...
  • Page 14 1. Open the hood.  The device automatically switches to radiant warmer mode. 2. Set the therapy adjuster Warmer to Off (Fig. 6/1) and confirm with the rotary knob. Fig. 6 Radiant warmer mode Information on verification of the scale Babyleo TN500...

  • Page 15: Establishing A Level Position

    Pay attention to the spirit level NOTE If necessary, unevenness in the floor need to be compensated by aligning the device by tilting the mattress tray. ✓ The level position has been established. Information on verification of the scale Babyleo TN500...

  • Page 16: Removing The Mini Wall

    ● Remove the cable on the rear of the sensor wall, guide it through the hose grommet in the center of the sensor wall, and remove. 2. Remove the mattress from the mattress tray. Fig. 10 Mattress Information on verification of the scale Babyleo TN500...

  • Page 17: Establishing The Top Position

    Access to the service menu 1. In the main menu bar, tap the System setup... button. 2. In the System setup dialog window, open the System > Service page. 3. Enter the password 0000 and confirm. Information on verification of the scale Babyleo TN500...
  • Page 18  General information displays the following data for the scale (Fig. 13/1): – Status (Scale status). – Serial number (Serial number) and software version (Software version). – High-resolution weight (Weight (full resolution) [g]) and weight in clinical operation (Weight [g]). Information on verification of the scale Babyleo TN500...

  • Page 19: Calibration Procedure

    Calibration in the service menu is easier for the user and is described below. 3.12.1 Preparing the scale To be able to correctly check the measurement limits during calibration, the scale must be set to zero. Information on verification of the scale Babyleo TN500...
  • Page 20 The change counter’s readings can be read out (see chapter 3.11 Access to the service menu) and compared with the entries on the labels (see chapter 3.5.1 Device labeling and 3.5.2 Labeling the weighing module). Information on verification of the scale Babyleo TN500...
  • Page 21 Maximum weight exceeded Maximum tare weight NOTE The following message appears if the maximum tare weight is exceeded: Load is too high for zeroing. Fig. 16 Load is too high for zeroing Information on verification of the scale Babyleo TN500...
  • Page 22 This page has been left blank intentionally. Information on verification of the scale Babyleo TN500...
  • Page 23 This page has been left blank intentionally. Information on verification of the scale Babyleo TN500...
  • Page 24 Manufacturer Drägerwerk AG & Co. KGaA Moislinger Allee 53 – 55 23542 Lübeck Germany +49 451 8 82-0 9034001 – 6016.170 en © Drägerwerk AG & Co. KGaA Revision: 2.0 – 2019-07 Subject to change without notice. Will not be replaced in the event of modifications. Á9034001nÈ...
