End of Life Management
• There are no components which contain stored electrical energy after the device has
been shut off
• Does not contain hazardous substances requiring special handling and treatment
• Dispose of in an environmentally responsible manner in accordance with regional
requirements
• Contact Bio Compression Systems if you have questions or concerns regarding
disassembly and disposal
Manufacturer's EMC Declaration
Electromagnetic Emissions
Emissions
RF emissions
CISPR 11
RF emissions
CISPR 11
Harmonic emissions
IEC 61000-3-2
Voltage fluctuations/
flicker emissions
IEC 61000-3-3
Electromagnetic Immunity
Immunity Test
IEC 61000-4-2 Electrostatic Discharge Immunity
IEC 61000-4-3 Radiated RF Field Immunity
IEC 61000-4-3 Proximity Fields from RF Wireless
Communications Equipment
IEC 61000-4-4 Electrical Fast Transients
IEC 61000-4-5 Surge Immunity
IEC 61000-4-6 Conducted RF Immunity
IEC 61000-4-8 Magnetic Field Immunity
IEC 61000-4-11 Voltage Dips
IEC 61000-4-11 Voltage Interruptions
Compliance
Group 1 The device uses RF energy only for its internal functions. Therefore, its RF
emissions are very low and are not likely to cause any interference in nearby
electronic equipment.
Class B
Not The device is suitable for use in all establishments, including domestic
applicable establishments and those directly connected to the public low voltage power supply
network that supplies building used for domestic purposes.
Not
applicable
Electromagnetic Environment - Guidance
Immunity Test Level
±8kV contact, ±2, 4, 8kV air discharge
80MHz – 2.7GHz, 10V/m, AM 80% at 1kHz
IEC 60601-1-2, Section 8.10, Table 9
±2kV/100kHz power, ±1kV/100kHz signal
±0.5, 1kV line to line, ±0.5, 1, 2kV line to ground
150kHz - 80MHz, 3V in whole range, 6V
RMS
ISM, AM 80% at 1kHz
30A/m, 50 or 60Hz
0% U per 0.5 cycles, 0% U
T
0% U per 250/300 cycles
T
13
in amateur radio and
RMS
per 1.0 cycle, 70% U per 25/30
T T
cycles
