INSTRUCTIONS for
Powder-Washing Attachment
These INSTRUCTIONS are for experienced operators. If you are not fully familiar with the principles of operation and safe practices for oxy-fuel gas
equipment, we urge you to read our booklet "Precautions and Safe Practices for Welding, Cutting and Heating", Form 2035. Do not permit untrained
persons to operate this equipment. Do NOT attempt to operate this equipment until you have read and fully understand these instructions. If you do
not fully understand these instructions, contact your supplier for further information.

OPERATION

Connecting

1. Attach regulators to the oxygen and fuel gas cylin-
ders. Follow all instructions supplied with the regu-
lators.
2. Attach oxygen and fuel gas hose to the regulators
and to the torch, after making sure all metal seat-
ing surfaces are clean. Tighten all connection nuts
with a wrench.
3. Attach nozzle to torch head, and tighten connec-
tion nut with a wrench.

Adjusting Gas Pressures

Fuel Gas: Open the fuel gas valve about one turn. Turn in
the pressure-adjusting screw on the acetylene regulator
until its delivery-pressure gauge registers the desired pres-
sure (see cutting chart on page 4). Then immediately
close the acetylene valve.
Oxygen: Open the cutting oxygen valve by depressing
its valve lever fully. Turn in the pressure-adjusting screw
on the oxygen regulator until its delivery-pressure gauge
registers the desired pressure (see cutting chart on page
4). Then release the cutting oxygen lever.
NOTE: When gaugeless regulators are used, do not
open torch valves. Merely turn in the pressure-
adjusting screws to the desired pressure as in-
dicated on the scales of the regulator caps.
Be sure this information reaches the operator.
You can get extra copies through your supplier.
C-62 Cutting Torch
and

Testing for Leaks

Every cutting outfit should be thoroughly tested for leaks
after it is first hooked up, and at regular intervals there-
after. After all connections have been made, make sure
all valves on the torch handle are closed. Then turn in
the regulator pressure-adjusting screws until the oxy-
gen delivery-pressure gauge registers 60 psi and the
fuel gas delivery-pressure gauge registers 10 psi. Us-
ing Leak Test Solution that is suitable for oxygen ser-
vice, such as P/N 998771 (8 oz. container), check for
leaks at the cylinder valves, the cylinder-to-regulator con-
nections, the regulator-to-hose connections, and the hose-
to-torch connections. If bubbling at any point indicates
leakage, tighten the connection. If this does not stop leak-
age, close the appropriate cylinder valve, open the corre-
sponding torch valve to remove all pressure from the line,
and finally release the regulator pressure-adjusting screw
by turning it counterclockwise. Then break the leaky con-
nection, wipe metal seating surfaces with a clean dry
cloth, and examine them for nicks and scratches. Re-
make the connection(s) and retest. Do not try to light the
torch until you are satisfied that all connections are gas-
tight.
After lighting the torch and adjusting the flames, use
leak test solution to check for leakage at all torch valves
and at the nozzle nut.
F-9178-K
May, 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OXWELD C-62 and is the answer not in the manual?

Questions and answers

Summary of Contents for ESAB OXWELD C-62

  • Page 1 INSTRUCTIONS for F-9178-K May, 2009 C-62 Cutting Torch Powder-Washing Attachment These INSTRUCTIONS are for experienced operators. If you are not fully familiar with the principles of operation and safe practices for oxy-fuel gas equipment, we urge you to read our booklet “Precautions and Safe Practices for Welding, Cutting and Heating”, Form 2035. Do not permit untrained persons to operate this equipment.
  • Page 2 reaD anD unDerstanD instruction manual Before installing or operating. protect Yourself anD others! caution these instructions are for experienced operators. if you are not fully familiar with the prin- ciples of operation and safe practices for gas welding and cutting equipment, we urge you to read our booklet, “precautions and safe practices for gas Welding, cutting, and heating,”...
  • Page 3 Then let occurred to your distributor or to ESAB Remanufacturing the two springs drop out in your hand. Finally, dislodge Center, Florence SC for repair.
  • Page 4 Cutting Valve Lever: To remove, merely drive out the ING NOZZLES. Use the OXWELD tools recommended fulcrum spiral-pin, using a drill or piece of rod (7/32-in. in the charts on page 4 or OXWELD nozzle cleaning com- diam. or smaller). pound.
  • Page 5 CUTTING & SPECIAL NOZZLES INFORMATION OPERATING DATA Nozzle Cleaning Data and Part Numbers OXY-ACETYLENE NOZZLES Cleaning Tool Steel (in.) Nozzle Regulator Press. (psig)* Min. Size Part No. Preheat Cutting Thickness Size Oxygen Acetylene Hose Size 1502 SERIES ( preheat holes) CUTTING: 1502 Series 1/4"...
  • Page 6 powder tube into the connection (185W05). Using POWDER WASHING ATTACHMENT ASSEM- two wrenches, tighten the connection. BLY INSTRUCTIONS 4. Position the powder valve (55Y49) as shown in Fig. 2 with the lever in line with the cutting valve lever on the Before attempting to use the powder attachment, read torch.
  • Page 8 ESAB Welding & Cutting Products, Florence, SC Welding Equipment COMMUNICATIONS GUIDE - CUSTOMER SERVICES A. CUSTOMER SERVICE QUESTIONS: Telephone (803) 664-5540/Fax: (800) 634-7548 Order Entry Product Availability Pricing Hours: 8:30 AM to 5:00 PM EST Order Changes Saleable Goods Returns...
