CAS SW1N Series Manual

10/06/2008
CAS (USA) Corporation 99 Murray Hill Parkway East Rutherford, NJ 07073

CALIBRATION MODE WEIGHT SETTINGS FOR SW1N SERIES

1. Make sure the scale is off. Remove the platter assembly (metal and/or plastic platform.)
2. On the right hand side you will find a hole and a screw at the bottom. This is the sealing screw.
Remove the sealing screw and then turn the scale upside down to find the calibration screw and
silver plate located on the right side of the bottom of the scale (if keyboard is facing you and you
tilt the scale upwards by the front.)
3. Remove the calibration screw and the silver plate. Under the plate is the calibration switch.
4. Press and hold the switch while turning the scale on. The display will show "ONE" and then "CAL
1".
5. The "TARE" key advances through the cal settings whereas the "UNIT" goes down. The
"ZERO" key enters the cal setting.
6. Press the "UNIT" key twice to go to "CAL 10". Press the "ZERO" key to enter into the settings.
7. The display will flash "UNIt" and then a number. 0 is for calibrating in KG and 1 is for calibrating in
LBS. Select the unit that is being used for calibration and press the "ZERO" key.
8. The display will flash "CAPA" and then show the current capacity. The chart below shows the
capacities to be set. Only use the capacity setting that is shown on the front of the scale. The
"UNIT" key will increment the flashing digit while the "TARE" key selects the digit that will flash. If
1 was selected for the unit follow the settings listed under 1. If 0 was selected for the unit follow
the settings under 0.
Display
Shows
Unit 1
Capacity
5LBS 00005
10LBS 00010
20LBS 00020
50LBS 00050
Weight used
ld
in Cal
during
calibration.
Cannot
00000
less then full
capacity
W-dP
5LBS 3
10LBS 3
20LBS 2
Display
Shows
Capacity
2KG 00002
5KG 00005
10KG 00010
20KG 00020
This is part Weight
3 of a three used in Cal
point 3 during
calibration calibration.
be during cal Cannot be
but 3 00000 but
less then
full capacity
W-dP
2KG
5KG
10KG
AD-Series
0
3
3
3
