- Page 1 TruVision HD-TVI 1080P Wedge Camera Installation Guide TVW-2401/TVW-4401 P/N 1073183-EN • REV A • ISS 07JUL16...
-
Page 3: Table Of Contents
Content Product overview 4 Camera description 7 Installation 8 Operating temperature range 15 Program 15 Menu tree 18 Specifications 19 Legal and Regulatory information 20 Installation Guide... -
Page 4: Product Overview
Product overview This is the Installation Guide for the TruVision high definition TVI wedge camera TVW-2401/TVW-4401. This guide describes a standard installation. Package contents Camera assembly 3 M4 x 25 mm (cable harness not screws and 3 shown) anchors for wall or ceiling installation Camera drill... - Page 5 Torx wrench Adapter plate Adapter plate drill Installation guide template • Equipment disposal instructions Installation Guide...
- Page 6 Lens adjustment HD-TVI video test tool cable 12 VDC connector (2 terminal connectors with positive and negative indicators) Installation Guide...
-
Page 7: Camera Description
Camera description ② ③ ① ④ ⑤ TVI video output HD-TVI video test cable Power cable Menu button Camera base Note: The HD-TVI wedge camera should only be connected to a DVR that supports a TVI signal. Installation Guide... -
Page 8: Installation
Installation To install the camera on a surface: Use the camera drill template to mark the mounting holes. Follow all local safety regulations. Drill through the mounting surface. If you need to route the cables from the bottom of the camera, drill a larger hole in the mounting surface for the cable harness. - Page 9 Install the mounting base to the surface using two of the M4 x 25 mm screws and anchors. If routing the cable harness through the ceiling, do so prior to mounting the camera. Loosen the locking screw, located near the lens assembly.
- Page 10 Locking Screw Lens Adjustment Tool Rotation Tilt Note: Please do not remove the foam ring attached to the lens. This foam ring is required to reduce the glare of IR illuminators. Tighten the locking screw and re-install the housing cover to the camera assembly using the Torx wrench.
- Page 11 To install the camera using the adapter plate: Use the adapter plate drill template to mark the holes. Follow all local safety regulations. Drill through the mounting surface. If you need to route the cables from the bottom of the camera, drill a larger hole for the cable harness.
- Page 12 Install the adapter plate to the using two of the M4 x 25 mm screws and anchors. Using the Torx wrench, loosen the four screws to remove the housing cover from the device. Install the camera base to the adapter plate using the two M4 x 8mm screws.
- Page 13 Loosen the locking screw located near the lens assembly. Align the lens adjustment tool with the two small holes located on the camera assembly. Rotate (pan) the camera assembly using the lens adjustment tool until the lens is positioned in the correct location. The tool is also used to adjust the tilt angle.
- Page 14 Lens Adjustment Tool Rotation Tilt Note: Please do not remove the foam ring attached to the lens. This foam ring is required to reduce the glare of IR illuminators. Tighten the locking screw and re-install the housing cover to the camera assembly using the Torx wrench.
-
Page 15: Operating Temperature Range
Operating temperature range The operating temperature of the TVW-2401/4401 cameras is -30 to +60 °C (-22 to +140 °F). Program The HD-TVI video output allows the camera to be programmed using the OSD (On Screen Display) feature. The camera OSD can be accessed via the recorder. - Page 16 Select the PTZ protocol TruVision Coax and click Menu button to call up the camera menu. For more details, refer to the TVI DVR user manual. Call up the camera OSD (On Screen Display) menu To set up the camera: Camera Settings of the DVR, access the PTZ menu and select the TruVision-Coax...
- Page 17 From the DVR: To select an OSD item, click the directional buttons up/down. To adjust the value of a selected item, click the directional buttons left/right. From the camera: To select an OSD item, push the Menu button up/down. To adjust the value of a selected item, push the Menu button...
-
Page 18: Menu Tree
Menu tree Installation Guide... -
Page 19: Specifications
Specifications Power supply 12 VDC Current 420 mA max. 5 W max. Power consumption Weight (net) 260 g (0.57 lb.) Dimensions 99.5 x 97 x 46.8 mm (3.92 x 3.82 x 1.84 in. ) Installation Guide... -
Page 20: Legal And Regulatory Information
Legal and Regulatory information Copyright: © 2016 United Technologies Corporation, Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks and patents: Trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products. - Page 21 harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. FCC conditions: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
- Page 22 (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For more information see: www.recyclethis.info. Contact information: For contact information, see www.interlogix.com or www.utcfssecurityproducts.eu Installation Guide...
