4.10 IP QoS

IP QoS helps you to arrange the network resources more reasonably. This function can
guarantee the minimum bandwidth or limit the maximum bandwidth for the specified IP address(or
IP range) to make full use of the supplied bandwidth. You can configure the IP QoS on this page,
shown as in Figure 4-43
Enable IP QoS – Enable or disable IP QoS function. You can enable this function for better
performance and experience with online games and other interactive applications such as
VoIP. The following IP Range QoS configuration won't be effective unless it is enabled.
Choose Bandwidth Type – Specifies your network connection type. Here you can select
either ADSL or Other.
•
ADSL – Select if you are using a dial-up connection.
•
Other – Select if you are using other connection types.
Bandwidth Apply – Specifies the bandwidth you get form your ISP. If you are not clear about
that, please contact with your ISP for help.
IP Range – Specifies the IP range of this entry.
Mode – There are 2 types of mode: Minimum Bandwidth Guarantee and Maximum
TL-WR642G 108M Wireless Router User Guide
Figure 4-43
53
