Click the Delete All button to delete all entries
Click the Next button to go to the next page and Click the Previous button to return the previous
page.
Note:
The function won't take effect until the router reboots.

4.7 Forwarding

Figure 4-24 The Forwarding menu
There are four submenus under the Forwarding menu (shown in Figure 4-24): Virtual Servers,
Port Triggering, DMZ and UPnP. Click any of them, and you will be able to configure the
corresponding function. The detailed explanations for each submenu are provided below.

4.7.1 Virtual Servers

Virtual servers can be used for setting up public services on your LAN, such as DNS, Email and
FTP. A virtual server is defined as a service port, and all requests from the Internet to this service
port will be redirected to the computer specified by the server IP. Any PC that was used for a
virtual server must have a static or reserved IP Address because its IP Address may change
when using the DHCP function. You can set up virtual servers on this page, shown in Figure
4-25:
Service Port - The numbers of External Ports. You can type a service port or a range of
service ports (the format is XXX – YYY, XXX is the start port, YYY is the end port).
IP Address - The IP Address of the PC providing the service application.
Protocol - The protocol used for this application, either TCP, UDP, or All (all protocols
supported by the router).
Status - The status of this entry either Enabled or Disabled.
TL-WR642G 108M Wireless Router User Guide
Figure 4-25 Virtual Servers
39
