TP-Link TL-WR642G User Manual page 59

To add static routing entries:
1. Click the Add New button. (pop-up Figure 4-42)
2. Enter the following data:
Destination IP Address - The Destination IP Address is the address of the network or host
that you want to assign to a static route.
Subnet Mask - The Subnet Mask determines which portion of an IP Address is the network
portion, and which portion is the host portion.
Gateway - This is the IP Address of the gateway device that allows for contact between the
router and the network or host.
3. Select Enabled or Disabled for this entry on the Status pull-down list.
4. Click the Save button to save it.
To modify or delete an existing entry:
Click the Modify in the entry you want to modify. If you want to delete the entry, click the
Delete.
Modify the information.
Click the Save button.
Click the Enable All button to make all entries enabled.
Click the Disabled All button to make all entries disabled.
Click the Delete All button to delete all entries.
TL-WR642G
Figure 4-41 Static Routing
Figure 4-42 Add or Modify a Static Route Entry
108M Wireless Router User Guide
52
