TERMINAL CONNECTIONS
Connect the unit as in the diagram below.
■ EXTERNAL DIMENSIONS unit: mm (inch)
*Euro type connector terminals (4, 5 and 6) provided only with 2-ch. option.
■ CONNECTION DIAGRAM
POTENTIOMETER
max.
+ 1
3
2
INPUT 1 2
– 3
1
min.
POTENTIOMETER
max.
+ 4
3
5
INPUT 2 2
–
6
1
min.
*For dual redundant communication.
Note: The section enclosed by broken line is with 2-ch. option.
18 (.71) 6.5
(.26)
4 5 6
*
1 2 3
INTERNAL
BUS A
INTERNAL
BUS B*
INTERNAL POWER
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
LOCKING CLAMP
90 (3.54)
WIRING INSTRUCTIONS
■ EURO TYPE CONNECTOR TERMINAL
Applicable wire size: 0.2 to 2.5 mm
Stripped length: 7 mm
R5-MS
POSITIONING GUIDE
2
