IDTECH 2DScan FX200 Quick Start Manual page 7

Section 2
INSTALLATION AND OPERATION
⚫
Connect 2DScan FX200 USB to the Host
•
Connecting with USB Cable
(Reference picture)
⚫
Connect 2DScan FX200 RS to the Host
•
Connecting with USB Cable
(Reference picture)
⚫
Connecting with RS232 Cable
Insert USB Cable (USB male head)
into Host's (female) USB connector
1. Insert USB Cable (RJ45 male
head) into 2DScan cable slot
2. Insert USB Cable (USB male head)
into Host's (female) USB connector
