  • Page 1 ValueScan III IDBB-4244MRB Barcode Scanner User Manual Version: 1.4 Date: 25 August 2019...
  • Page 2 Revision History Version Date Description Page # 2019/10/18 Initial release 2019/11/20 Updated scanner specifications 2019/12/17 Added Presentation Mode Modified the description of Disable code39 transmit and Enable code39 2020/08/25 40-41 transmit. Updated manual style.
  • Page 3 Regulatory Compliance FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4 CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. Note: All brands and trademarks are the property of their respective owners. Note: The specifications contained herein are subject to change without notice.

  • Page 5: Table Of Contents

    Contents 1. INTRODUCTION ................6 2. UNPACKING .................. 8 3. GET STARTED ................9 3.1. I ..................9 NSTALLATION 3.1.1. Set Up Your Scanner ................9 3.2. H .................. 10 OW TO SCAN 4. CONTROLS AND SETTINGS ............11 4.1. V .........

  • Page 6: Introduction

    1. Introduction Your VALUESCAN III is a 1D CCD scanner that has been configured at the factory with default settings. Because many host systems have unique formats and protocol requirements, ID TECH provides a wide range of configurable features that may be selected using this bar-code-based configuration tool.
  • Page 7 • (EAN, 13mil/0.33mm, PCS 90%) Drop resistance: 1.5 meters onto concrete • Auto-sensing (presentation) mode available • ※ Just scan the Presentation Mode barcode on the stand to easily switch to presentation mode for the VALUESCAN III scanner. Presentation Mode...

  • Page 8: Unpacking

    2. Unpacking Make sure the following items were included in your package: • Scanner x1 • Stand x1 • Quick Start Guide x1 • USB Cable x1 When you receive your scanner, open the package immediately and inspect for shipping damage. If you discover any damage, contact the shipping company and file a claim.

  • Page 9: Get Started

    3. Get started This chapter provides information about installing, connecting, and using your scanner. 3.1. Installation Install your scanner with the steps below. 3.1.1. Set Up Your Scanner 1. Plug the RJ45 connector into the scanner’s RJ45 port, until it clicks. 2.

  • Page 10: How To Scan

    3.2. How to scan VALUESCAN III emits a light bar when it is scanning. To scan a barcode, make sure the aiming beam crosses every bar and space of the barcode. This bar needs to cross the bar code horizontally to decode it.

  • Page 11: Controls And Settings

    4. Controls and settings Customize your scanner to work efficiently. VALUESCAN III offers many features to match your preferences. The following section provides information about changing your scanner’s controls and settings 4.1. Version information setting code Version (custom) 000A0 Display internal string (custom)

  • Page 12: Interface Mode Setting Codes

    4.2. Interface Mode Setting Codes VALUESCAN III supports USB HID and virtual COM. By default, your scanner can detect the interface automatically. When it detects USB, it selects HID as the interface. USB-HID (Default) 000602 USB Virtual Com 000603 Note: If you use the scanner to communicate with your computer via a serial interface (e.g., COM1 ...

  • Page 13: Scan Mode Setting Codes

    4.3. Scan Mode Setting Codes Trigger mode (default) 013340 Continuous scan mode 013344 Presentation mode 013380 Key delay 013342 Single not triggered 013341 Key delay not triggered 013343 Auto flashing 013345...

  • Page 14: Sound Setting Codes

    4.4. Sound Setting Codes Sound on (default) 014201 Sound off 014200 Buzzer frequency 2048 0145800 High volume sound 014300 Low volume sound 014301 Buzzer frequency 2731 0145AAA...

  • Page 15: Character Delete, Insert, And Replacement Settings

    4.5. Character Delete, Insert, and Replacement Settings Code ID off (default) 01400 Code ID on 01401 Rear code ID on 01402 Display code front character (default) 0201x Hide code front blank 0200[SPACE] Display code rear character (default) 0203 Hide code rear character n (“n”...
  • Page 16 Enable A replace 0 in code 02060A Display rear characters (default) 023300 Hide rear 5 characters 023305 Hide rear 1 characters 023301 Display front characters (default) 023400 Hide front 5 characters 023405 Display middle characters (default) 023900 Hide 5 middle characters 023905 Forward start from 4th character...
  • Page 17 FUNC3 replace with 3 0162051 FUNC4 replace with 4 0163054 Disable enter replace (default) 0182013 Enter replace with 5 0182055...

  • Page 18: Serial Port Settings

    4.6. Serial Port Settings Baud rate 600bps 000701 Baud rate 1200bps 000702 Baud rate 2400bps 000703 Baud rate 4800bps 000704 Baud rate 9600bps (default) 000705 Baud rate 19200bps 000706 Baud rate 38400bps 000707 Baud rate 57600bps 000708 Baud rate 115200bps 000709 Serial Port: No Check 001200...
  • Page 19 Serial port: RTS/CTS 001202 Serial port handshake timeout 0013020 Serial port handshake timeout 0013050 Serial port 8-bit data 00080 Serial port 7-bit data 00081 Serial port 1 stop bit 00090 Serial port 2 stop bits 00091 Serial port No parity check 001000 Serial port odd parity check 001001...

  • Page 20: Normal Function Setting Codes

    4.7. Normal Function Setting Codes Enable upload setting barcodes 02501 Disable upload setting barcodes (default) 02500 FUNC cast light upon cancel (default) 01640 Disable change 02510 All uppercase 02511 All lowercase 02512 Uppercase interchange with lowercase 02513 Enable command beep 01411 Disable command beep 01410...
  • Page 21 00160 Fastest transmit rate 001500 Medium transmit rate (default) 001502 Lower transmit rate 001504 Lowest transmit rate 001506...

  • Page 22: Refix Suffix Setting

    4.8. Prefix / suffix setting 0212@\r CR+LF 0213@\r\n All barcodes (rear) add ETX 0211@[ETX] All barcodes (front) add F2 02160081 All barcodes (rear) add F2 02110081 Cancel all barcodes (rear) format character 0210@ Add STX before barcodes 0217@[STX] Cancel all boots before barcodes 0215@ Add prefix...
  • Page 23 02242 Clear all prefix 02220 Clear all suffix 02200 Enter hidden front character mode 02340 Enter hidden rear character mode 02341 Enter hidden middle character mode 02342 Enter the hidden Nth character mode 02343...

  • Page 24: Multi-Language Setting Codes

    4.9. Multi-Language Setting Codes English (default) 0005000 Canada (French) 0005001 Dutch (Netherlands) 0005002 Spain (Spanish) 0005003 Argentina (Latin American) 0005004 Brazil (Portuguese) 0005005 Denmark (Danish) 0005006 UK (English) 0005007 Italy (Italian142) 0005008 France (French) 0005009 German (Germany) 0005010...
  • Page 25 Norway (Northern Sami) 0005011 Sweden, Finland (Swedish, Finnish) 0005012 Slovak (Slovakia) 0005013 Portuguesa (Portuguese) 0005014 Czech Republic (Czech) 0005015 Belgium (Dutch) 0005016 Turkey-F 0005017 Turkey-Q 0005018 Poland (Polish214) 0005019 Switzerland (German, French) 0005020...
  • Page 26 Croatia (Srb-Crt) 0005021 Hungary (Hungarian) 0005022 Japan (Japanese) 0005023 Russia (Russian) 0005024 Arabic (Egypt) 0005025...

  • Page 27: Character Table

    4.10. Character table (For adding prefixes and suffixes) 1001 1003 1002 1004 1006 1005 1007 1009 1008 Backspace 1010 1012 Line 1011...
  • Page 28 1013 1015 Enter 1014 1016 1018 1017 1019 1021 1020 1022 1024 1023...
  • Page 29 1025 1027 1026 1028 1030 1029 1031 1033 1032 SPACE 1034 1036 “ 1035...
  • Page 30 1037 1039 ‘ 1038 & 1040 1042 1041 1043 1045 1044 1046 1048 Note: Used to set address/prefix/suffix 1047...
  • Page 31 1049 1051 Note: Note: Used to set address/prefix/suffix Used to set address/prefix/suffix 1050 Note: Used to set address/prefix/suffix 1052 1054 Note: Note: Used to set address/prefix/suffix Used to set address/prefix/suffix 1053 Note: Used to set address/prefix/suffix 1055 1057 Note: Note: Used to set address/prefix/suffix Used to set address/prefix/suffix...
  • Page 32 1056 Note: Used to set address/prefix/suffix 1058 1060 < 1059 1061 1063 1062 > 1064 1066 1065 1067 1069...
  • Page 33 1068 1070 1072 1071 1073 1075 1074 1076 1078 1077 1079 1081...
  • Page 34 1080 1082 1084 1083 1085 1087 1086 1088 1090 1089 1091 1093...
  • Page 35 1092 1094 1096 1095 1097 1099 1098 1100 1102 1101 1103 1105...
  • Page 36 1104 1106 1108 1107 1109 1111 1110 1112 1114 1113 1115 1117...
  • Page 37 1116 1118 1120 1119 1121 1123 1122 1124 1126 1125 1127 1129 Delete...
  • Page 38 1128 1130 1132 1131 1133 1135 1134 1136 1138 1137 1139 1141 HOME...
  • Page 39 1140 INSERT 1142 1144 Page up 1143 Delete 1145 1147 Page down Left arrow 1146 Right arrow 1148 1149 Down arrow Up arrow...

  • Page 40: Enable And Disable Barcodes

    4.11. Enable and Disable Barcodes Enable code39 00221 Disable code39 00220 Code39 ID as m 0031m Enable code39 Full ASCII (default) 00231 Disable code39 Full ASCII 00230 Disable code39 MOD43 Check (default) 00240 Enable code39 MOD43 Check 00241 Enable code39 transmit check 00251 Disable code39 transmit check 00250...
  • Page 41 Enable code39 transmit “*” 00281 Disable code32 (default) 01950 Enable code32 Note: It will affect code39. 01951 Code39 TAB Mode 0212M\t System characters hiding code32 01961 System characters sending code32 01960 Setting the CODE39 to a min. length of 1 Software version available 003201 before and after V7.53...
  • Page 42 Code39 min. length 2 (default) Software version available after V7.53 00322 Code39 min. length 3 Software version available after V7.53 00323 Enable UPC-A (default) 00341 Disable UPC-A 00340 UPC-A ID as e 0049e Enable UPC-A change to EAN-13 00391 Disable UPC-A change to EAN-13 (default) 00390 Transmit UPC-A check digit...
  • Page 43 Enable UPC-E (default) 00351 Disable UPC-E 00350 UPC-E ID as f 0050f Enable UPC-E change to UPCA 00381 Disable UPC-E change to UPC-A (default) 00380 UPC-E hiding system characters 00431 UPC-E sending system characters 00430 UPC-E sending check digits 00441 UPC-E not sending check digits 00440...
  • Page 44 EAN-13 ID as d 0051d Transmit EAN-13Check digit (default) 00461 No-transmit EAN-13 check digit 00460 Enable EAN-13 change to ISBN 00481 Disable EAN-13 change to ISBN (default) 00480 Enable EAN-13 change to ISSN 01501 Disable EAN-13 change to ISSN (default) 01500 Enable EAN-13 multiple verify 00541...
  • Page 45 EAN-8 ID as c 0052c EAN-8 transmit check digit (default) 00571 EAN-8 No-transmit check digit 00570 EAN-8 hide system digit 00561 EAN-8 display system digit (default) 00560 Enable 5-digit supplement 00552 Enable 2-digit supplement 00551 Enable 2-digit & 5-digit supplements 00553 Disable supplement (default) 00550...
  • Page 46 Code93 ID as i 0066i Enable code93 multiple verify 00681 Disable code93 multiple verify (default) 00680 Enable Code93 MOD47 (default) 01901 Disable Code93 MOD47 01900 Enable code128 (default) 00691 Disable code128 00690 Code128 ID as a 0081a Disable code128 multiple verify (default) 00840 Enable code128 multiple...
  • Page 47 Disable codabar 00850 Codabar ID as v 0094v Codabar min. length 4 008704 Codabar start / stop character transmission 00861 Codabar start / stop character without transmission (default) 00860 Enable interleaved 2 of 5 (default) 00961 Disable interleaved 2 of 5 00960 Interleaved 2 of 5 ID as n 0104n...
  • Page 48 No transmission of check on Interleaved 2 of 5 ID 00991 Transmission of check on Interleaved 2 of 5 ID 00990 Enable bank mode 01001 Disable bank mode 01000 Enable industrial 2 of 5 (default) 01061 Disable industrial 2 of 5 01060 Industrial 2 of 5 ID as o 01130...
  • Page 49 MSI min. length 4 011804 Enable Plessey 01161 Disable Plessey (default) 01160 Plessey ID as t 0117t Plessey min. length 3 011903 Enable code11 (default) 01261 Disable code11 01260 code11 ID as u 0131u Code11 min. length 4 012804 Code11 auto CK check 01271 Code11 C check (default) 01272...
  • Page 50 Code11 CK check 01273 Enable Matrix 25 (default) 01461 Disable Matrix 25 01460 Matrix 25 ID as q 00147q Matrix 25 min. length 2 014802 Matrix 25 min. length 3 014803 Enable postal 25 01571 Disable postal 25 (default) 01570 Postal 25 ID as r 0158r Postal 25 min.
  • Page 51 Enable aerial 25 01871 Disable aerial 25 (default) 01870 Aerial 25 ID as p 0188p Aerial 25 min. length 7 018907 All EAN change to ISSN 02371 Disable EAN change to ISSN (default) 02370 All EAN change to ISBN 02361 Disable EAN change to ISBN (default) 02360...
  • Page 52 Disable GS1 Omni-directional (default) 01670 GS1 Omni ID as j 0168j Enable GS1 Limited 01771 Disable GS1 Limited (default) 01770 GS1 Limited ID as k 0178k Note: The setting code type is code128. When generating a barcode, you must add ^3 before the barcode;...

  • Page 53: Prefix / Suffix Code Setting Instructions

    5. Prefix / Suffix Code Setting Instructions The pre/suffix code is divided into a common pre/suffix code and a private pre/suffix code. The common pre/suffix code means that the pre/suffix code is added before a barcode; the private pre/suffix code refers to a certain type of barcode, such as code 128 codes and code 39, a specific barcode to which the pre/suffix is added.

  • Page 54: Adding An Exclusive Suffix Code

    For example, to add the common suffix code A, the hexadecimal setting code is 02110041; to add the common prefix code A, the hexadecimal setting code is 02160041. Additionally, you must add a character after the barcode and then add Enter. To add the character + after the bar code and then add Enter, use the setting code 0213@+\r;...

  • Page 55: Leep Time Setting Button Timeout Setting

    Likewise, to add a specific barcode with a prefix code, all Code 128 codes are needed before the letter A; there are two ways to do so:: To accumulate, use 0218A. 5.3. Sleep time setting / button timeout setting 1. Sleep time setting code: 0310nnn If X seconds of sleep is required and calculated in hexadecimal (4 for base), the formula is x/4=NNN.

  • Page 56: Hiding Characters

    5.4. Hiding Characters The hidden suffix character setting code is 0233nn. To hide a suffix of 5 characters, the setting code is 023305. The hidden prefix setting code is 0234nn. If 023405 hides a prefix of 5 characters, the value of nn changes the number of hidden characters.

  • Page 57: Barcode Types Code Table

    6. Barcode Types Code Table (00) (01) code128 (03) EAN8 (04) EAN13 (05) UPCA (06) UPCE (09) CODE93 (0A) GS1 OMNI (0B) GS1 LIMI (0D) CODE39 (0E) Interleaved 2 of 5 (0F) Industrial 2 of 5 (10) Aerial25 (11) Matrix 25 (12) Postal 25 (13)

  • Page 58: Ascii Table 1

    7. ASCII Table 1 The table below lists specific keys and code values (ASCII code values available for standard characters). 0x80 0x81 0x82 0x83 0x84 0x85 0x86 0x87 0x88 0x89 0x8A 0x8B Insert 0x8C Home 0x8D Page up 0x8E Page down 0x91 Delete 0x8F...

  • Page 59: Tip 1

    7.1. Tip 1 ASCII = [F3]‘0’‘2’‘1’‘6’‘I’ [STX] Binary = [F3] + 0x30 + 0x32 + 0x31 + 0x37 + 0x49 + 0x02 Setting barcode --> 7.2. Tip 2 ASCII = [F3] + ‘0’ + ‘2’ + ‘1’ + ‘6’ + ‘0’ + ‘9’ + ‘0’ + ‘2’ And if CODE93 is added with Home prefix code: ASCII = [F3] + ‘0’...

  • Page 60: Ascii Table 2

    8. ASCII Table 2 Decimal Hexadecimal Character Null Header start Text start Text end Transmission end Query Confirmation Ring backspace Level positioning character Line feed / new line Vertical positioning character Form feed / new page Enter Shift-out Shift-in space "...
  • Page 61 Decimal Hexadecimal Character < >...
  • Page 62 Decimal Hexadecimal Character Decimal Hexadecimal Character Data link translation Device control 1 Device control 2 Device control 3 Device control 4 Reverse confirmation Synchronous idle Transmission block Cancel Media end Interchange Translation File separator Group separator Record separator Unit separator...
  • Page 63 Decimal Hexadecimal Character...
  • Page 64 Decimal Hexadecimal Character...

  • Page 65: Specifications

    9. Specifications Standard Feature Symbologies UPC-A, UPC-E, EAN-13, EAN-8, Codabar, Code 39 Full ASCII, China Post, Plessey, MSI, Code 93, Code 128, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, Code 11, ISBN, ISSN, Code32 (Italian Pharmcode), Code39 extended, GS1-128 and ITF-14, SISAS, GS1 Omnidirectional, GS1 Limited, Aviation25,...
