- Page 1 Premium 120 and 170 Portable Clotheslines Product Manual...
-
Page 2: Carton Contents
Leg Assembly - LH assembly and use. In this way, you will benefit Leg Assembly - RH from all of the design features and enjoy safe use of the product. Thank you for choosing Hills. Leg Brace Hanging Bracket Warning Door Adaptor •... - Page 3 Introduction FD12000 - LI FD12000 Fig 1 Fig 1 Fig. 1 Spreader and Hinge Assembly Spreader and Hinge Assembly Spreader and Hinge Assembly Arm Assembly Arm Assembly Arm Assembly Hanging Bracket Hanging Bracket Hanging Bracket Leg Brace Leg Brace Leg Brace Line Line Line...
-
Page 4: Installation
Installation The Hills Portable Clothesline is quick and easy to assemble. Just follow the steps below which are suitable for both the 17m (10 line) and 12m (8 line) models. Note: All diagrams in this manual show the Portable 120 model. - Page 5 Installation Step 2 – Attach the Legs to the Hinge Assemblies 2.1 Fasten the legs as shown in Steps 1-4. Step 1 Locate the M6 nut on the moulded leg section of the hinge moulding (Fig. 5). *Nylon ring of the nut must face outward. Step 2 Fit the leg tube (ensuring mount hole is oriented as shown in Fig.
- Page 6 Installation Step 3 – Attach the Brace to the Legs 3.1 Using the M6 x 16 countersunk screws, attach the Leg Brace to the 4 threaded inserts, Fig 9 using the hex key (Fig. 9). 3.2 Fasten securely. 3.3 Repeat at other end. Fig.
- Page 7 Installation Step 5 – Attach the Arms 5.1 Locate the arms into the recess in each end of the Hinge Assemblies, ensuring the screw holes and insert fasteners align. 5.2 Insert the M6 x 12 low profile screws and fasten securely using the hex key (Fig. 11). Fig 11 Note: Ensure the arms are assembled with the curve up (Fig.
- Page 8 Installation Fig 13 Fig 14 Step 6 – Attach the Line 6.1 Fasten the line to the innermost line tensioner as shown in steps 1-11. Step 1 Thread a line tie o cap onto one end of the PVC line (Fig. 13). Step 2 Insert the line into the slot of an inner line tie o saddle and through the side (Fig.
- Page 9 Installation Step 6 When you reach the tie o end of the line, thread another line tie o cap (Fig. 18). Step 7 Insert the line into the slot of the last line tie o saddle (Fig. 19). Warning: Do not tighten the line yet. FD12000 - LINE ART Step 8 Repeat steps for the other side.
- Page 10 Installation Step 7 – Line tensioning To re-tension lines if required: 7.1 Remove either cover cap on the arm. 7.2 Untie the existing line. 7.3 Repeat steps as described on pages 8 and 9. Note: Do not over tighten the line, as you can distort the frame. Step 8 –...
- Page 11 Installation Fig 22 8.2 Place the folded end on the ground (Fig. 24). 8.3 Release the latch at the other end, and fold the legs, while bringing the product to a vertical position (Fig. 25). Note: Check the legs are not caught in the lines before trying to unfold. Always ensure your hands are positioned where they will provide support and will not be caught in moving parts.
-
Page 12: Step 9 - Hanging Bracket
Installation Step 9 – Hanging Bracket To hang your Portable Clothesline for convenient storage, a hanging bracket has been included (Fig. 26). 9.1 The hanging bracket can be fastened to almost any wall or vertical surface, using appropriate fasteners (not supplied). The hanging bracket and door adaptor can be used over most doors. -
Page 13: Care And Maintenance
floor. When placing washing on the Portable Clothesline, ensure the weight is balanced and washing is placed evenly on both sides. The Hills Portable Clothesline can be used almost anywhere but should not be used in strong wind conditions unless it is placed in a protected area and secured. -
Page 14: Year Warranty
Warranty 10-Year Warranty* For products purchased in Australia: *In addition to other rights and remedies that may be available under any applicable law, Our goods come with guarantees that cannot AMES Australasia Pty Ltd warrants to the purchaser be excluded under the Australian Consumer of the product (customer) that this Clothesline Law. - Page 15 Customer Service Centre during their local business hours: Australia 1300 300 564 New Zealand 0800 021 027 Email hhl.enquiries@amesau.com Hills Websites hillshome.com.au Hills Home Living hillshome.com.au/need-help/ Hills Consumer Advice...
- Page 16 AMES Australasia Pty Ltd A.B.N. 89 169 427 061 Issue Mar 2019 HD10777c...
