140252 BW-100 Door Upgrade
I N S T R U C T I O N S
Part Description
ASSY-TRACK & DOOR BW1 RETRO
ASSY-LH END PANEL BW100
ASSY-RH END PANEL BW100
HOUSING-PULLEY LEFT BW100
HOUSING-PULLEY RIGHT BW100
GUARD-PULLEY BW100
GUIDE-WEIGHT BW-100
STUD ASSY-PLATE PULL BW100 RH
STUD ASSY-PLATE PULL BW100 LH
WELD ASSY-WEIGHT LEFT BW RET
WELD ASSY-WEIGHT RIGHT BW RET
CHANNEL-DOOR BW100 SPACER
PULLEY-BW100
WELDNUT-MACHINED
1/2 " OPEN/CLOSED BUSHING
#8-18 X 7/16 PH IND XTRNL TRX (DALE
SCREW)
Enclosure Top
#8 Self-Tapping Screw
Acorn Nut
#10 Nuts
Loctitie
Lock Washers
Cover - Label Clear
Label - Data Plate
Label - Left Drill Template
Label - Right Drill Template
Qty
1
1
1
1
1
2
2
1
1
1
1
2
2
2
2
10
1
6
2
4
1
6
1
1
1
1
FM08-301
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Henny Penny BW-100
Summary of Contents for Henny Penny BW-100
- Page 1 FM08-301 140252 BW-100 Door Upgrade I N S T R U C T I O N S Part Description ASSY-TRACK & DOOR BW1 RETRO ASSY-LH END PANEL BW100 ASSY-RH END PANEL BW100 HOUSING-PULLEY LEFT BW100 HOUSING-PULLEY RIGHT BW100 GUARD-PULLEY BW100...
- Page 2 A QUALIFIED TECHNICIAN MUST PERFORM THE UPGRADE. TO AVOID INJURY OR PROPERTY DAMAGE, BEFORE STARTING THIS PROCEDURE, MOVE THE POWER SWITCH TO THE “OFF” POSITION. DISCONNECT THE MAIN CIRCUIT BREAKER AT THE CIRCUIT BREAKER BOX, OR UNPLUG THE SERVICE CORD AT THE RECEPTACLE. ALSO, TURN OFF THE MAIN GAS SUPPLY TO THE COOKER, OR POSSIBLE EXPLOSION COULD Remove unit and perform work in...
- Page 3 5. Using a 3/8 nut-driver or socket, remove the three (3) nuts closest to the door only. Set nuts aside for the next step. 6. Locate the counter-weight tracks and install using the nuts removed in the previous step. Repeat steps 6 &7 for the other side of the unit. 7.
- Page 4 11. Remove the old door assembly by removing the six (6) nuts from the back side with a 3/8in. wrench or socket. 12. Using the new door assembly, install in the same location as the old door assembly and tighten. Apply Loctite to the studs before installing the nuts.
- Page 5 16. Locate the pulley guard. Place center hole on the stud and tighten down with a phillips head bit or screwdriver as shown in Figure a. 17. Locate the pulley included in the kit. Place the cable in the groove of the pulley so the eyelet is going down the back side of the pulley.
- Page 6 22. Locate the counterweights for the appropriate side. Place the counterweight onto the newly installed track as shown in Figure a. 23. As shown in Figure b, place the eyelet into the counterweight. 24. Apply Loctite then, tighten with a phillips head bit or screwdriver as shown in Figure c.
- Page 7 29. Locate the new top cover included in the kit. Place the cover on top of the unit. 30. Tighten the bolts as they were removed in the first operations. 31. Locate the pulley cover included in the kit. Using a phillips head bit or screwdriver, secure the cover to the unit.
