- Page 1 Henny Penny Island Warmer Model HMI-103 Model HMI-105 OPERATOR’S MANUAL...
- Page 3 During this time, any frypot that fails due to manufacturing or workmanship issues will be replaced at no charge for parts, labor, or freight. Henny Penny will either install a new frypot at no cost or provide a new or reconditioned replacement fryer at no cost.
-
Page 4: Table Of Contents
3-3. Operating with Product ... 3-1 3-4. Shut Down and Clean Up ... 3-2 3-5. Operating Controls ... 3-3 Section 4. TROUBLESHOOTING ... 4-1 4-1. Troubleshooting Guide ... 4-1 GLOSSARY ... G-1 Distributor Lists - Domestic and International TABLE OF CONTENTS Model HMI-103/105 Page... -
Page 5: Section 1. Introduction
1-3. PROPER CARE 1-4. ASSISTANCE SECTION 1. INTRODUCTION The Henny Penny Island Warmers are a basic unit of food pro- cessing equipment used to display the food product and maintain the temperature of hot foods in a commercial food service operation. -
Page 6: Safety
1-5. SAFETY The only way to ensure safe operation of the Henny Penny Island Warmer is to fully understand the proper installation, operation, and maintenance procedures. The instructions in this manual have been prepared to aid you in learning the proper procedures. Where information is of particular importance or is safety related, the words NOTICE, CAUTION, or WARNING are used. -
Page 7: Section 2. Installation
The Henny Penny Island Warmer is tested, inspected and expertly packed to insure arrival at its destination in the best possible condition. The unit has been bolted to a wooden skid. -
Page 8: Electrical Connection
Volts Phase Watts Amps Wires HMI-103 120/208 2400 HMI-103 120/208 2400 HMI-103 120/240 2600 HMI-103 120/240 2600 HMI-105 120/208 3900 HMI-105 120/208 3900 HMI-105 120/240 4200 HMI-105 120/240 4200 HMI-103 2600 HMI-105 4200 Model HMI-103/105 11.0 11.0 18.0 13.0 17.5 12.0 11.3... -
Page 9: Section 3. Operation
Also, refer to the Installation section to be sure the cabinet has been properly installed. Before using, the Henny Penny Island Warmer should be thoroughly cleaned as indicated in the Shut Down and Clean Up Section of this manual. -
Page 10: Shut Down And Clean Up
Do not use a water jet (pressure sprayer) to clean the unit, or component failure could result. 4. Clean around electrical controls and components with a damp cloth. 5. Clean glass with a non-streaking liquid glass cleaner and a soft cloth. Model HMI-103/105... -
Page 11: Operating Controls
Cooling Fan Maintains cooler metal surface temperatures Manual Reset Shuts off the heat if a cooling fan fails; the High Limits access panel must be removed and the high limit manually reset Model HMI-103/105 FUNCTION... - Page 12 3-5. OPERATING CONTROLS (Continued) Figure 3-1 Figure 3-2 Figure 3-3 Model HMI-103/105...
- Page 13 3-5. OPERATING CONTROLS (Continued) Figure 3-4 Figure 3-5 Figure 3-6 Model HMI-103/105...
-
Page 15: Section 4. Troubleshooting
More detailed troubleshooting information is available in the Technical Manual, available at www.hennypenny.com, CAUSE • Only hold product for recommended times • Turn to a higher setting • Turn to a higher setting • Check fuse and replace if necessary • Replace with recommended bulb or 1-800-417-8405 or 1-937-456-8405. Model HMI-103/105 CORRECTION... -
Page 17: Glossary
G L O S S A R Y HENNY PENNY HOLDING CABINETS a round device located inside the cabinet that measures the inside air temperature and sends that information to the control panel a metal assembly located in the water pan in the bottom of the unit that... - Page 18 NOT be used to clean a holding cabinet the area in the cabinet that holds water for creating humidity inside the cabinet Model HMI-103/105...
