For Sj300/L300P Series - Hitachi SRW-0J Instruction Manual

10.1 Type of LCD screen, configuration LCD
LCD screens are classified five types. Each of mode's operation way is written on 10.3
1. Monitor mode A
Monitor Item 1
Function Mode Simple Display
2. Monitor mode B
Monitor Item 2
Monitor Item 3
3. Trip mode
(display each data during trip )
ERR1
The data on trip
4. Warning monitor
WARN
Contents of warning
5. Function mode
>Code No. Name of group
Individual
Chapter 10 LCD display and operating for SJ300/L300P series
(display monitor screen display in top row and
function mode simple display in bottom row.)
Ex. :
(display the monitor screen display on top row and bottom row.)
Ex. :
Factor
Ex. :
Inverter status
(display each data during warnig )
Factor code
Ex. :
(selecting function)
Ex. :
setting value
FM 0060.00H
>A001 REM
FM 0060.00H
Iout 0022.5A
ERR1 OC. Accel
F 037.00Hz ACC
WARN W025
Lim-L > FS
>A001 F-SET
SELECT REM
