Hitachi SRW-0J Instruction Manual page 43

Communication
236 stop
bit
Communication
237
waiting time
(NOTE 1) SJ300 series only .
No. Function name
238 O adjustment
239 OI adjustment
240 O2 adjustment
Thermistor adjust-
241
ment
AM off set adjust-
242
ment
243 AMi adjustment
Ami off set adjust-
244
ment
Debug mode
245
selection
246 UP/DOWN selection
247 Reset selection
Reset f frequency
248
matching selection
Overload advance
249
notice level
250 O zero adjustment
251 OI zero adjustment
252 O2 zero adjustment
253 Autotuning selection
st
1 motor constant
254
selection
nd
2 motor constant
255
selection
st
1 allowable motor
256
selection
nd
2 allowable motor
257
selection
st
1 motor pole
258
selection
Chapter 10 LCD display and operating for SJ300/L300P series
>C075 RS485
STOPBIT 1BIT
>C078 RS485
WAIT 0000ms
Display
>C081 O-ADJUST
TOP 00000
>C082 OI-ADJUST
TOP 00000
>C083 O2-ADJUST
TOP 00000
>C085 THERM
ADJUST 0105.0
>C086
AM-MONITOR
OFFSET 00.0V
>C087 AMI-MON
ADJUST 080
>C088 AMI-MON
OFFSET 04.0mA
>C091 INITIAL
DEBG OFF
>C101 UP/DWN
DATA NO-STR
>C102 RESET
SELECT ON
>C103 RESET
f-Mode ZST
>C111 OL
LEVEL2 0000.0A
>C121 O-ADJUST
ZERO 00000
>C122 OI-ADJUST
ZERO 00000
>C123 O2-ADJUST
ZERO 00000
>H001 AUX
AUTO NOR
>H002 AUX
DATA NOR
>H202 2AUX
DATA NOR
>H003 AUX
K 005.50kW
>H203 2AUX
K 005.50kW
>H004 AUX
P 4P
1BIT (1bit) / 2BIT(2bit)
0 – 1000(ms)
(12/15)
Data range
0 – 65535
0 – 65535
0 – 65535
0.0 – 1000.0
0.0 – 10.0(V)
0 – 255
0.0 – 20.0(mA)
OFF(No display) / ON(display)
NO-STR(No frequency data)
STR(Keep frequency data)
ON(Trip cancel during ON) / OFF(Trip cancel
during OFF)
TRP(Valid only during trip<Cancel during
ON>)
ZST(OHz star) / fST(Start f-equaling)
0.00 - 2.00*rated current(A)
0 – 65535
0 – 65535
0 – 65535
NOR(Invalid) / NRT(Valid (the motor does not
rotate))/AUT(Valid (the motor rotates))
NOR(Hitachi general purpose motor data) /
AUT(Autotuning data) / ON-AUT(Autotuning
data with online autotuning)
NOR(Hitachi general purpose motor data) /
AUT(Autotuning data) / ON-AUT(Autotuning
data with online autotuning)
0.20 - 75.0(kW)
0.20 - 75.0(kW)
2P,4P,6P,8P (pole)
(NOTE 1)
(NOTE 1)
(NOTE 1)
(NOTE 1)
