- Page 1 VL10K GUIDE ON HD INSTRUCTIONS (Applies to P/Ns 3610250, 3610251 & 3610252) REIMANN & GEORGER CORPORATION MARINE PRODUCTS BUFFALO, NY P/N 6112002 04/23/18...
-
Page 2: Table Of Contents
VL10K Guide On Wood Bundle VL100132” ................8 VL10K Guide On Bag of Bolts ...................... 8 LIST OF FIGURES FIGURE DESCRIPTION PAGE Guide On Support Assembly ......................4 Guide On Wood Assembly ......................5 Guide On Adjustments ........................6 RGC MARINE PRODUCTS PHONE: (716) 895-1156... -
Page 3: Safety
MANUAL AND YOUR VERTICAL LIFT MANUAL. FAILURE TO DO THIS CAN LEAD TO EQUIPMENT MISUSE WITH RESULTING DAMAGE AND/OR SERIOUS PERSONAL INJURY. CONTACT YOUR RGC MARINE DEALER IF YOU HAVE ANY QUESTIONS. Do not install this kit without first replacing any damaged or defective parts. - Page 4 Do not operate the lift under the influence of drugs, alcohol, or medication. 10. Keep people and pets clear during operation of the lift. 11. Keep fingers and clothing clear of all moving parts. 12. Never allow people in the boat any time it is suspended above the water on the platform. WARNING: DO NOT STAND OR WALK ON THE PLATFORM WHILE IT IS IN ANY RAISED POSITION.
-
Page 5: Installation And Setup
2 INSTALLATION AND SET UP 2.1 PRE-INSTALLATION CHECKS Do not assemble this kit or any other component of the lift if any part appears to be damaged. Do not weld or other wise modify any portion of the lift. Such alterations may weaken the structural integrity of the lift and void the warranty. -
Page 6: Vl Guide On Assembly
Figure 2-1. Guide On HD Support Assembly 2.4 GUIDE ON ASSEMBLY (Refer to Figure 2-2) Position a Guide On (4), on top of the HD Upper Tube assembly (2), so that the aluminum channel (pre-assembled to wood) rests on top of both Upper Tube mounting plates. Insert two spring nuts (B), into the channel as shown and turn to lock in place on channel ridge. - Page 7 Figure 2-2. Guide On Assembly...
-
Page 8: Vl Guide On Adjustments
2.5 GUIDE ON ADJUSTMENTS (Refer to Figure 2-3) Loosen u-bolt nuts (F), on load tubes to adjust distance between Guide Ons (4), to best suit boat width and wave conditions. Retighten the load tube nuts at this time. NOTE: ADJUST GUIDE ON WIDTH SO BOATS WEIGHT REMAINS CENTERED ON LIFT TO AVOID DAMAGE TO LIFT OR BOAT. -
Page 9: Inspection And Maintenance
3 INSPECTION AND MAINTENANCE 3.1 GENERAL MAINTENANCE RULES Do not allow persons other than authorized service personnel to repair this equipment. Inspect bumper and guide on kits regularly for deterioration. Replace them immediately if they are worn. Do not weld or otherwise modify the lift. Such alterations may weaken the structural integrity of the lift and invalidate your warranty. -
Page 10: Parts Lists
4 VL GUIDE ON HD PARTS LIST - 10K Each reference number or letter in the following parts lists can be matched with the reference number or letter referred to in the illustrations of the instruction manual. WARNING: FAILURE TO APPLY A SUITABLE LUBRICANT TO THE MATING SURFACES OF STAINLESS STEEL THREADED FASTENERS MAY CAUSE GALLING AND/OR SEIZING OF ASSEMBLY. - Page 11 Reimann & Georger Corporation Marine Products This product is warranted by RGC Marine Products to the original purchaser to be free from defects in material and workmanship under normal use for a period of two years from the date of purchase.
