Lens Holder - Tech Lighting ELEMENT E3-L AE Series Installation Instructions Manual

Install the Lenses (Optional
9A
LENSES

LENS HOLDER

1
Place lenses (max. 2, optional) inside the lens holder.
9B
Vertical Alignment
2
3
Horizontal Alignment
Use the lens orientation guides to align linear spread
2
lenses vertically or horizontally.
)
2
Guides
2
Guides
9C
3
Line up the legs of the lens holder with the notches on the
3
lamp holder and push the lens holder on.
SAVE THESE INSTRUCTIONS!
7400 Linder Ave.
Skokie,
847.410.4400
www.element-lighting.com
© 2019 Tech Lighting, L.L.C. All rights reserved. The "Element" graphic
is a registered trademark of Element. Element reserves the right to
change specifications for product improvements without notification.
8
3
3
IL 60077
