- Page 1 LH-2510 Leveling Base Head You’re on steady ground ™...
- Page 2 An additional bushing is included to make the bottom socket compatible with most tripods. When the terrain or lack of time prevent adjusting each leg of a tripod, the LH-2510 allows for precise angle adjustment and a secure lock down once you have set the level.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Key Features Operation Mount Base to Tripod Mount Head to Base Leveling the Camera and Head Specifications Warnings... -
Page 4: Key Features
KEY FEATURES 1/4″-20 threaded mounting post Rubber base pad Fluid head (10° adjustment) 3/8″-16 treaded mounting Rubber mounting pad socket Tightening screws 1/4″-3/8″ bushing Bubble level 3/8″-1/4″ bushing Ratchet-style tightening screw Allen wrench... -
Page 5: Operation
OPERATION 1. Mount Base to Tripod Screw the leveling base head into the tripod until it is tight. Note: If the tripod has a 1/4″-20 threaded post, first screw the 3/8″ – 1/4″ bushing into the bottom socket and tighten with a flat head screwdriver. -
Page 6: Leveling The Camera And Head
OPERATION 3. Leveling the Camera 1. Turn the locking knob counterclockwise to loosen the leveling base. 2. Looking at the bubble level, adjust the level of the base until the bubble rests in the center of the circle. 3. Turn the locking knob clockwise to tighten and secure the leveling base. -
Page 7: Warnings
• Do not operate in salt water. Dry the head if it becomes wet. • Avoid long-term exposure to sunlight (to prevent damage to your camera). • Keep out of reach of children. Visit our website at ObenSupports.com for more Oben products. - Page 8 www.obensupports.com...
