- Page 1 GH3W-15 3-Way Geared Head You’re on steady ground ®...
- Page 2 INTRODUCTION Thank You for choosing Oben! The Oben 3-Way Geared Head fine-tunes camera tilt, angle, and pan so your camera is always aligned with the horizon, and your subject fits perfectly in the picture frame. The three independent gear movements assure perfect aim with pinpoint precision.
- Page 3 • Avoid long-term exposure to sunlight. • Remove the camera from the head during setup and transport. • Keep out of reach of children. • All images are for illustrative purposes only. Visit our website at ObenSupports.com for more Oben products.
- Page 4 KEY FEATURES...
- Page 5 KEY FEATURES Quick-Release Lock Quick-Release Plate Bubble Levels Front Tilt Knob Forward Tilt Scale Pan Knob Quick Lock Lateral Tilt Knob Lateral Tilt Scale Pan Scale 3/8-16 Mounting Socket...
- Page 6 OPERATION Mounting the Head to a Tripod Align the tripod’s 3/8-16 stud with the head’s mounting socket, and hand-tighten the head by rotating it clockwise. Attaching the Quick-Release Plate to a Camera 1. Loosen the quick- release lock, and remove the quick- release plate from the clamp.
- Page 7 OPERATION Mounting a Camera to the Head 1. Loosen the quick- release lock. 2. Insert one side of the quick-release plate into the clamp, and then lower the other side of the plate into the clamp. 3. Support the camera and lens with one hand while you tighten the quick-release lock...
- Page 8 OPERATION Operating the Head 1. Turn and hold the spring-loaded quick lock to disengage the gears and rapidly tilt or rotate the camera. 2. Release the locking collar to engage the gears, and use the adjustment knobs to fine-tune the front tilt, lateral tilt, and pan.
- Page 9 OPERATION Front Tilt Knob The front tilt knob controls the camera’s up/down tilt. The head tilts down to 90°, which is good for document and macro photography, and has an upward tilt of 30°. Lateral Tilt Knob The lateral tilt knob controls the camera’s side to side angle.
-
Page 10: Specifications
SPECIFICATIONS General Head Type 3-way geared head Base Mount 3/8-16 female Base Diameter 2.6 in. (6.6 cm) Camera Mounting Screw 1/4-20 male Load Capacity 15 lb. (6.8 kg) Number of Bubble Levels 3 Independent Pan Lock Material Aluminum Pan and Tilt Range Lateral Tilt -30°... -
Page 11: Warranty
WARRANTY Five-Year Limited Warranty This Oben product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of five (5) years from the original purchase date or thirty (30) days after replacement, whichever occurs later. - Page 12 Oben is a registered trademark of the Gradus Group. © 2022 Gradus Group LLC. All Rights Reserved.
