The schematics for the eZdsp
that accompanies this board. The schematics were drawn on ORCAD.
The TMS320F2804x supports +3.3V Input/Output levels
which are NOT +5V tolerant. Connecting the eZdsp to
a system with +5V Input/Output levels will damage the
TMS320F2804x. If the eZdsp is connected to another
target then the eZdsp must be powered up first and
powered down last to prevent lactchup conditions.
Appendix A
eZdsp
Schematics
TM
F2804x can be found on the CD-ROM
WARNING !
TM
F2804x
A-1
