1.0 Overview of the eZdsp
The eZdsp
TMS320F2804x digital signal processor (DSP) to determine if it meets their application
requirements. Furthermore, the module is an excellent platform to develop and run
software for the TMS320F2804x processor.
The eZdsp
allows full speed verification of F2804x code. Expansion connectors are provided
for any necessary evaluation circuitry not provided on the as shipped configuration.
To simplify code development and shorten debugging time, a C2000 Tools Code
Composer driver is provided. In addition, an onboard JTAG connector provides
interface to emulators, operating with other debuggers to provide assembly language
and 'C' high level language debug.
1.1 Key Features of the eZdsp
The eZdsp
1-2
TM
F2804x
TM
F2804x is a stand-alone card--allowing evaluators to examine the
TM
F2804x is shipped with a TMS320F2804x DSP. The eZdsp
TM
F2804x
TM
F2804x has the following features:
• TMS320F2804x Digital Signal Processor
• 100 MIPS operating speed
• 10K words on-chip zero wait state SARAM
• 128K words on-chip Flash memory
2
• 256K bits serial I C EEPROM memory
• 20 MHz. clock
• Expansion Connectors (analog, I/O)
• Onboard IEEE 1149.1 JTAG Controller
• 5-volt only operation with supplied AC adapter
• TI F28xx Code Composer Studio tools driver
• On board USB JTAG emulation connector
• 1 SCI UART channel
