2.1.1 Power Connector
The eZdsp
unit. The unit requires 500mA. The power is supplied via connector P6. If expansion
boards are connected to the eZdsp, a higher amperage power supply may be
necessary. Section 2.3.6 provides more information on connector P6.
TM
2.2 eZdsp F2804x Memory
The eZdsp includes the following on-chip memory:
The eZdsp can load ram for debug, or Flash can be programmed and run. For larger
software projects it is suggested to do a initial debug with on eZdsp F2804x module
which supports a total RAM environment. With careful attention to the I/O mapping in
the software the application code can easily be ported to the F2804x.
TM
F2804x is powered by a 5-Volt only power supply, included with the
• 2 blocks of 1K x 16 single access RAM (SARAM, M0,M1)
• 1 block of 8K x 16 SARAM (Lo,L1)
