Status Monitoring Interface:
The EDP Double Conversion UPS series is factory equipped with Ethernet connectivity, providing status information
regarding operation, alarm reporting, event notification via email and SNMP, and on-board web page for configura-
tion and local monitoring of UPS operation. Ethernet communication is TCP/IP ready and supports SNMP, SMTP,
SNTMP, and HTTP protocols.
EDP Double Conversion UPS Features:
All models have 120VAC/60Hz output.
•
Ethernet status monitoring standard.
•
High efficiency for economical line operation and longer run time from battery input.
•
Pure Sine Wave output.
•
Liquid Crystal Display (LCD) for local visual monitoring.
•
•
Input power factor, typically 0.7 or better (line mode).
•
Temperature compensated battery charger with battery temperature sensor.
•
Robust rectifier/charger and inverter circuits.
•
PWM controlled forced-air cooling.
•
Certified UPS product per IEC Standard 60950-1.
Complies with EMI/RFI limits of Standards EN 55022 and EN 55024.
•
Unpacking and Inspection:
Before installing this equipment, inspect the power supply for shipping damage or missing components. If the power
supply or other items were damaged in shipment, file a damage claim with the shipping company and contact your
Multilink representative immediately. Be sure to retain the original shipping carton and all packing material for the
power supply until you are certain that a warranty return will not be required.
All EDP Double Conversion power supplies include:
1 Power supply, ready for installation in cabinet
1 Power harness
1 Battery temperature sensor cable
2 Relay and Timer connectors
1 Installation and Operations guide
Missing or Damaged Items:
If items are found to be damaged or missing, contact the shipping company and your Multilink representative
immediately. All damage claims must be filed with the shipping company conveying your equipment. Your Multilink
representative will be able to assist with immediate equipment needs, if necessary.
Original Shipping Container:
When returning a unit for service, use its original shipping container and all original packing materials. Items
damaged as a result of improper packaging will not be covered under provisions of warranty service.
Other Items:
If you ordered other items such as batteries and cable kits for use with the power supply, ensure also that those items
did not sustain shipping damage. As with the power supply itself, all damage claims must be filed with the shipping
company and your Multilink representative should be contacted immediately.
Page 9
Visit
gomultilink.com
for new product releases!
9
