Refer to the following chart for event abbreviation descriptions for all alarm and fault events. Alarms or faults that are
currently active will have an abbreviation appended with "A". When the alarms are cleared, an event occur showing the
removal of the alarm. This abbreviation will be appended with an "R".
Alarm Description
AC Input Voltage High
AC Input Voltage Low
Frequeny High
Frequency Low
AC Line Voltage Failure
Battery Voltage High
Battery Voltage Low
Battery Temp High
Battery Temp Low
Temp Sensor Disconnected
Temp Sensor Shorted
Battery Status Menu:
Battery Status
Battery 36.0V 0.0A
Battery Status
Temp 25.0C / 77.0F
Battery Status
Charging Float
Configuration Menu:
Config Date
Config Date
2018-07-23
Page 22
Active Alarm Abbreviation
ACHA
ACLA
FQHA
FQLA
ACFA
BVHA
BVLA
BTHA
BTLA
TSOA
TSSA
Displays the current measured battery voltage and charge/disharge current.
Use the Right button (second button from left) to select next item.
Battery temp measured by external temp probe. Displays Celcius and Farenheit.
Indicates the state of the charger. OFF, Bulk, and Float states are displayed.
Allows the user to change the date. This view is similar for all menu items.
Press the Down button (third from the left) to enter the selected items
submenu. Any items that are change and not saved by pressing the Enter button
will revert its previously stored state.
The date that can be changed may be selected using the Right or Left buttons.
The selected item will be underlined. Use the Down button to select the new date.
Press the Enter button (right most button from left) to save the new date.
Press the Back button to return. Dates that are not saved will return to previously
save date.
Visit gomultilink.com
Recovered Alarm Abbreviation
for new product releases!
ACHR
ACLR
FQHR
FQLR
ACFR
BVHR
BVLR
BTHR
BTLR
TSOR
TSSR
