Performance Main Menu:
Performance
AC In 120.0V 3.0A
Performance
AC Out 120.0V 2.0A
Performance
Battery 24.0V 0.0A
Performance
Frequency In 60.0Hz
History Menu:
History
System Events 0005
History
Event Time 0000:00:00
History
Event List
EV: 0001 FQLA
2018-07-23 13:30:02
Page 21
AC Input voltage and current as measured by the UPS.
Use the Right button (second button from left) to select next item.
Displays AC Output voltage and current as measured by the UPS.
Battery voltage and charge/discharge current as measured by the UPS.
Measured AC Input frequency.
Displays the number of events for the UPS.
Use the Right button to select next item.
This is the elapsed time of the current active event, such as On Battery.
Event list showing the history of all events for the UPS.
Press the Down button (third button from left) to enter the list.
The currently viewed event number and alarm/fault event that occurred.
Time and date of the event are shown on this line. Up to 1,000 events may be
shown. Press the Down button to enter the list. Press the Left button (Left most
button) to return to the History menu. User may have to repeartly press this
button to return to the upper level menu.
