Platform: DBALL2
Firmware: FORD6 Remote Start Ready (RSR) Installation
Update Alert: Firmware updates are posted to the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Installation Guide
The FORD6 firmware for DBALL2 is an all-in-one door lock and override module compatible with
specific Ford and Lincoln vehicles. This guide supports the installation of a DBALL2 in Remote Start
Ready (RSR) mode with or without a Plug & Play (THFD1) T-Harness (optional). This solution offers
three (3) configuration options to control your system: 3x OEM Lock Remote Start Activation, RF
System or SmartStart (all sold separately).
Two (2) key required for module programming.
This module can only be flashed and configured using XpressVIP at www.directechs.com or using the Directechs
Mobile application for smartphones. Refer to
Remote Start Ready (RSR) is a function that enables the interface module to remote start the vehicle
completely on its own. Consequently, there is no need for an aftermarket or an OEM remote starter in order to
start the vehicle from a distance.
Important!
This product is NOT compatible with vehicles equipped with a manual transmission.
Index
Vehicle Application Guide................................................................................................................................................
Installation (Wiring Diagrams & Vehicle Wiring Reference Charts)
Type 1 with T-Harness (THFD1)......................................................................................................................................
Type 1 without T-Harness................................................................................................................................................
Type 2 with T-Harness (THDF1)......................................................................................................................................
Type 2 without T-Harness................................................................................................................................................
SmartStart/XL202 Installation Notes...............................................................................................................................
Programming
Module Programming......................................................................................................................................................
Module Programming - 2 Keys are required....................................................................................................................
Key2 GO Programming for 40-bit key types ONLY (using 1 key)...................................................................................
Feature & Option List.......................................................................................................................................................
Feature Programming......................................................................................................................................................
LED Diagnostics & Troubleshooting................................................................................................................................
Parking Light Error Codes...............................................................................................................................................
Limited One-Year Consumer Warranty............................................................................................................................
Quick Reference Guide...................................................................................................................................................
SmartStart is equipped with D2D, which means it can be connected to an interface module and used in Remote
Start Ready (RSR) mode without the use of a remote starter. See the Module Programming section for more
information.
® Ford is a registered trademark and property of Ford Motor Company.
the Module Programming section on page n
Rev.: 20170516
for more information.
02
03
04
05
13
14
16
17
18
18
19
20
21
22
24
25
26
© 2017 Directed. All rights reserved.
