Xpresskit DBALL Installation Manual

Hide thumbs Also See for DBALL:
Table of Contents

Advertisement

Quick Links

Platform: DBALL/DBALL2
Firmware: FORD3 Range Extender Ready (RXT) Installation
Update Alert: Firmware updates are posted to the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Installation Guide
This guide supports the installation of a DBALL in Range Extender Ready (RXT) mode. This solution
offers two (2) configuration options to control your system: Optional RF Kits or SmartStart (both sold
separately).
Range Extender Ready (RXT) is used to dramatically increase the factory remote start activation range
compared to the factory transmitter. Refer to the Quick Reference Guide for more information.
Important!
This product is ONLY compatible with vehicles equipped with a factory-installed remote starter.
Index
Vehicle Application Guide................................................................................................................................................
Installation
Installation (Wiring Diagram & Vehicle Wiring Reference Chart).....................................................................................
SmartStart/XL202 Installation Notes...............................................................................................................................
Programming
Module Programming......................................................................................................................................................
Feature & Option List.......................................................................................................................................................
Feature Programming......................................................................................................................................................
LED Diagnostics & Troubleshooting................................................................................................................................
Limited One-Year Consumer Warranty............................................................................................................................
Quick Reference Guide...................................................................................................................................................
SmartStart Compatible
SmartStart is equipped with D2D, which means it can be connected to an interface module and used in Range
Extender Ready (RXT) mode without the use of a remote starter. See the Module Programming section for more
information.
® Ford and Lincoln are registered trademarks and property of their respective companies.
Rev.: 20160810
