Platform: DBALL2
Firmware: HK9 Remote Start Ready (RSR) Installation
Update Alert: Firmware updates are posted on the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Installation Guide
Door lock interface and transponder override firmware compatible with Kia Sorento. It controls door
locks, factory security system, trunk release, door sensing, brake detection and many more functions.
This guide supports the installation of a DBALL2 in Remote Start Ready (RSR) mode. This solution
offers three (3) configuration options to control your system; 3x OEM Lock Remote Start Activation,
RF Kit or SmartStart (all sold separately).
Refer to Quick Reference Guide (QRG) at the end of this guide for more information on how to use
the various features offered with this product: Vehicle Takeover, Pit Stop, List of Available Commands
and Additional Features.
Remote Start Ready (RSR) is a function that enables the interface module to remote start the vehicle
completely on its own. Consequently, there is no need for an aftermarket or an OEM remote starter in order to
start the vehicle from a distance.
Important!
This product is NOT compatible with vehicles equipped with a manual transmission.
Index
Vehicle Application Guide...................................................................................................................................................
Installation
Wiring Diagram...................................................................................................................................................................
SmartStart/XL202 Installation Notes..................................................................................................................................
Programming
Module Programming.........................................................................................................................................................
Module Reset.....................................................................................................................................................................
Hard Reset.........................................................................................................................................................................
Feature & Option List..........................................................................................................................................................
Feature Programming.........................................................................................................................................................
LED Diagnostics & Troubleshooting...................................................................................................................................
Parking Light Error Codes..................................................................................................................................................
Limited One-Year Consumer Warranty...............................................................................................................................
Quick Reference Guide......................................................................................................................................................
SmartStart Compatible
SmartStart is equipped with D2D, which means it can be connected to an interface module and used in Remote
Start Ready (RSR) mode without the use of a remote starter. See the Module Programming section for more
information.
® Kia is a registered trademark and property of Kia Motors Corp.
Rev.: 20160711
02
03
04
05
06
06
07
07
08
09
10
11
© 2016 Directed. All rights reserved.
