Platform: DBALL2
Firmware: VW09 Remote Start Ready (RSR) Installation
Update Alert: Firmware updates are posted on the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Installation Guide
This guide supports the installation of a DBALL in Remote Start Ready (RSR) mode. This solution
offers three (3) configuration options to control your system: 3x OEM Lock Remote Start Activation,RF
Kit or SmartStart (both sold separately).
Refer to the Quick Reference Guide (QRG) at the end of this guide for more information on how to use
the various features offered with this product.
This firmware does not support transponder override. One (1) programmed OEM key must be wired
into the vehicle to complete installation of a remote starter.
During remote start sequence, the car console will indicate "no key located". This is normal due to
the key wrapped in the installation. At vehicle takeover, the message will disappear.
Remote Start Ready (RSR) is a function that enables the interface module to remote start the vehicle completely
on its own. Consequently, there is no need for an aftermarket or an OEM remote starter in order to start the vehicle
from a distance.
The installer must make sure the RFTD Output feature option is active in order to benefit from RSR. See the
Feature & Option List section for more information.
Index
Vehicle Application Guide.....................................................................................................................................................................
Installation (Wiring Diagrams & Vehicle Wiring Reference Charts)
Type 1..................................................................................................................................................................................................
Type 2..................................................................................................................................................................................................
Type 3..................................................................................................................................................................................................
Type 4..................................................................................................................................................................................................
Immobilizer Interface............................................................................................................................................................................
Programming
SmartStart/XL202 Installation Notes....................................................................................................................................................
Module Programming...........................................................................................................................................................................
Module Reset.......................................................................................................................................................................................
Feature and Option List........................................................................................................................................................................
Feature Programming..........................................................................................................................................................................
LED Diagnostics & Troubleshooting....................................................................................................................................................
Parking Light Error Codes....................................................................................................................................................................
Limited One-Year Consumer Warranty................................................................................................................................................
Quick Reference Guide.......................................................................................................................................................................
SmartStart Compatible
SmartStart 200/250 Revision B is equipped with D2D, which means it can be connected to an interface module and
used in Remote Start Ready (RSR) mode without the use of a remote starter. See the Module Programming
section for more information.
® Volkswagen is a registered trademark and property of its respective company.
Rev.: 20170420
02
03
05
07
09
11
13
14
16
17
17
18
20
21
22
© 2017 Directed. All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Xpresskit DBALL2

Summary of Contents for Xpresskit DBALL2

  • Page 1 Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Update Alert: Firmware updates are posted on the web on a regular basis. We recommend that you check for firmware and/or install guide updates prior to installing this product.

  • Page 2: Vehicle Application Guide

    Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 2 Vehicle Application Guide Vehicles Volkswagen EOS (Smart Key) • • • • • • • • • • • • • • • • • • Golf (Smart Key) •...

  • Page 3: Installation Type

    Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 3 Installation Type 1 Important! The Hood Pin and Remote Start Safety Override Switch are mandatory safety devices, but are NOT supplied with the DBALL. Diode 1A (-) PTS 2: pin 4...
  • Page 4 Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 4 Vehicle Wiring Reference Chart - Type 1 Wire Information Connector Information Function Color Pin Polarity Location Color Pins VW EOS (Smart key) 2013-2015 Gray/Yellow Headlight Switch. Black...
  • Page 5 Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 5 Installation Type 2 Important! The Hood Pin and Remote Start Safety Override Switch are mandatory safety devices, but are NOT supplied with the DBALL. Diode 1A (-) PTS 2: pin 4...
  • Page 6 Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 6 Vehicle Wiring Reference Chart - Type 2 Wire Information Connector Information Function Color Pin Polarity Location Color Pins VW Golf (Smart key) 2012-2014 Parking Light White/Black Headlight Switch.
  • Page 7 Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 7 Installation Type 3 Important! The Hood Pin and Remote Start Safety Override Switch are mandatory safety devices, but are NOT supplied with the DBALL. Electronic Steering Column...
  • Page 8 Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 8 Vehicle Wiring Reference Chart - Type 3 Wire Information Connector Information Function Color Pin Polarity Location Color Pins VW Jetta (Smart key) 2015-2017 White/Black or Gray/Red 3 Headlight Switch.
  • Page 9 Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 9 Installation Type 4 Important! The Hood Pin and Remote Start Safety Override Switch are mandatory safety devices, but are NOT supplied with the DBALL. Electronic Steering Column...
  • Page 10 Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 10 Vehicle Wiring Reference Chart - Type 4 Wire Information Connector Information Function Color Pin Polarity Location Color Pins VW Jetta (Smart key) 2011-2014 HS CAN High Orange/Black Data OBDII.

  • Page 11: Immobilizer Interface

    Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 11 Immobilizer Interface For vehicles with Keyless Entry you must remove battery from OEM key (your OEM remote may differ from the models shown in the illustrations) Method 1: Immobilizer interface with...
  • Page 12 Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 12 Method 2: Key wrap for Push-To-Start (PTS) COM Relay 2: Yellow/Red: 11 NO Relay 2: Brown/Red: 12 DBALL/ Prog. Button DBALL2 Immobilizer Receiver loops Note: OEM immobilizer receiver is located...

  • Page 13: Smartstart/Xl202 Installation Notes

    Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 13 SmartStart/XL202 Installation Notes The DBALL Remote Start Ready (RSR) solution offers three (3) configuration options to control your system: 3x OEM Lock Remote Start Activation, RF Kits or SmartStart (all sold separately). This section provides specific installation information for SmartStart and XL202.

  • Page 14: Module Programming

    Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 14 Module Programming Refer to the LED Diagnostics section for more information and for troubleshooting purposes. Important Make all the required connections to the vehicle, as described in the wiring diagram(s) found in this guide, and double check to ensure everything is correct prior to moving onto the next step.
  • Page 15 Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 15 Important: Do NOT press the brake pedal. Do NOT & Press the Push-to-Start (PTS) button once to turn ENGINE PUSH press the START STOP the ignition ON. The LED flashes green.

  • Page 16: Module Reset

    Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 16 Module Reset A module reset will only erase programming performed in the previous steps. All settings (firmware) and settings flashed to the module using the web config tool will not be affected.

  • Page 17: Feature & Option List

    Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 17 Feature & Option List It is recommended to configure all the features and options listed below using the configuration tool found on the module flashing page on www.directechs.com. The web offers more options; however, manual configuration of the features is possible using the information on this page.

  • Page 18: Led Diagnostics & Troubleshooting

    Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 18 LED Diagnostics & Troubleshooting Description Troubleshooting Module Programming Make sure the D2D harness is connected or that the 12 Volt is Module has no power. present between the red and black wires. If the 12 Volt is present, the module may be defective.
  • Page 19 Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 19 Description Troubleshooting External module synchronization The diagnostic data bus was not detected, therefore the OBDII feature is not supported. (Flashes red, SmartStart features will be limited. red then...

  • Page 20: Parking Light Error Codes

    Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 20 Parking Light Error Codes The parking lights on your vehicle will flash a specific number of times 3 seconds following an unscheduled shutdown or failure to start. Each flashing pattern is described below.

  • Page 21: Limited One Year Consumer Warranty

    Platform: DBALL2 Firmware: VW09 Remote Start Ready (RSR) Installation Rev.: 20170420 Page 21 Limited One Year Consumer Warranty For a period of ONE YEAR from the date of purchase of a Directed Electronics remote start or security product, Directed Electronics. (“DIRECTED”) promises to the original purchaser, to repair or replace with a comparable reconditioned piece, the security or remote start accessory piece (hereinafter the “Part”), which proves to be defective in workmanship or material...
  • Page 22 Quick Reference Guide DBALL2-VW09 Remote Start Ready (RSR) Installation Vehicle Takeover with Get In and Go* Pit Stop Mode The Pit Stop Mode feature is practical when you need to stop and run an errand, but wish to keep the engine running.
  • Page 23 Quick Reference Guide DBALL2-VW09 Remote Start Ready (RSR) Installation Remote Start Ready (RSR) List of Available Commands Remote Start Ready (RSR) is a function that enables the interface Note that the information below is for Viper, Clifford and Python models. Icons and module to remote start the vehicle completely on its own.
  • Page 24 Quick Reference Guide DBALL2-VW09 Remote Start Ready (RSR) Installation SmartStart Compatible Notes This system is compatible with Directed SmartStart 3.0. For a complete list of supported features, please visit www.mysmartstart.com. What is SmartStart? Now you can remote start, lock and unlock your car just by pushing a button on your smartphone;...
