Platform: DBALL2
Firmware: VW09
Update Alert: Firmware updates are posted on the web on a regular basis. We recommend
that you check for firmware and/or install guide updates prior to installing this product.
Installation Guide
The VW09 firmware for DBALL2 is an all-in-one door lock and override module compatible with specific
Volkswagen vehicles.
This firmware does not support transponder override. One (1) programmed OEM key must be wired
into the vehicle to complete installation of a remote starter.
During remote start sequence, the car console will indicate "no key located". This is normal due to
the key wrapped in the installation. At vehicle takeover, the message will disappear.
Index
Vehicle Application Guide.....................................................................................................................................................................
Type 1..................................................................................................................................................................................................
Type 2..................................................................................................................................................................................................
Type 3..................................................................................................................................................................................................
Type 4..................................................................................................................................................................................................
Immobilizer Interface............................................................................................................................................................................
Programming
Module Programming...........................................................................................................................................................................
Module Reset.......................................................................................................................................................................................
Feature and Option List........................................................................................................................................................................
Feature Programming..........................................................................................................................................................................
LED Diagnostics & Troubleshooting....................................................................................................................................................
Limited One-Year Consumer Warranty................................................................................................................................................
Quick Reference Guide........................................................................................................................................................................
® Volkswagen is a registered trademark and property of its respective company.
Rev.: 20170427
02
03
05
07
09
11
13
14
15
15
16
18
19
© 2017 Directed. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DBALL2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Xpresskit DBALL2

Summary of Contents for Xpresskit DBALL2

  • Page 1: Table Of Contents

    Installation Guide The VW09 firmware for DBALL2 is an all-in-one door lock and override module compatible with specific Volkswagen vehicles. This firmware does not support transponder override. One (1) programmed OEM key must be wired into the vehicle to complete installation of a remote starter.

  • Page 2: Vehicle Application Guide

    Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 2 Vehicle Application Guide The following table lists the vehicles and features which are compatible with this product. The number assigned to each year allows you to determine which installation type should be used for your vehicle.

  • Page 3: Installation (Wiring Diagrams & Vehicle Wiring Reference Charts) Type 1

    Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 3 Installation Type 1 VESCM VESCM conn. C (+) 12V: Driver side under dashboard (Brown conn.) pin 42 (+) Brake: Black/Red, pin 17 (+) Starter Output (-) Lock Output (+) 12V (-) Unlock Output...
  • Page 4 Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 4 Vehicle Wiring Reference Chart - Type 1 Wire Information Connector Information Function Color Pin Polarity Location Color Pins VW EOS (Smart key) 2013-2015 Gray/Yellow Headlight Switch. Black Parking Light Parking Light Interupt Red/Blue or Red/White Headlight Switch.

  • Page 5: Type 2

    Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 5 Installation Type 2 VESCM VESCM conn. C (+) 12V: Driver side under dashboard (Brown conn.) pin 42 (+) Brake: Black/Red, pin 17 (+) Starter Output (-) Lock Output (+) 12V (-) Unlock Output...
  • Page 6 Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 6 Vehicle Wiring Reference Chart - Type 2 Wire Information Connector Information Function Color Pin Polarity Location Color Pins VW Golf (Smart key) 2012-2014 Parking Light White/Black Headlight Switch. Black Parking Light Interupt Red/Blue or Red/White Headlight Switch.

  • Page 7: Type 3

    Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 7 Installation Type 3 (-) Ground (+) Starter Output (+) 12V (-) Lock Output (+) Brake Status Input (-) Unlock Output (AC) Tach Input (-) Trunk Release Output (+) Parking Lights Output (-) Trunk Status Input...
  • Page 8 Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 8 Vehicle Wiring Reference Chart - Type 3 Wire Information Connector Information Function Color Pin Polarity Location Color Pins VW Jetta (Smart key) 2015-2017 Parking Light White/Black or Gray/Red Headlight Switch. Black Parking Light Interupt Red/Yellow Headlight Switch.

  • Page 9: Type 4

    Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 9 Installation Type 4 (-) Ground (+) Starter Output (+) 12V (-) Lock Output (+) Brake Status Input (-) Unlock Output (AC) Tach Input (-) Trunk Release Output (+) Parking Lights Output (-) Trunk Status Input...
  • Page 10 Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 10 Vehicle Wiring Reference Chart - Type 4 Wire Information Connector Information Function Color Pin Polarity Location Color Pins VW Jetta (Smart key) 2011-2014 HS CAN High Orange/Black Data OBDII. Black HS CAN Low...

  • Page 11: Immobilizer Interface

    Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 11 Immobilizer Interface For vehicles with Keyless Entry you must remove battery from OEM key (your OEM remote may differ from the models shown in the illustrations) Method 1: Immobilizer interface with 556U (PTS) 556U or 556UW is sold SEPARATELY.
  • Page 12 Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 12 Method 2: Key wrap for Push-To-Start (PTS) COM Relay 2: Yellow/Red: 11 NO Relay 2: Brown/Red: 12 DBALL/ Prog. Button DBALL2 Immobilizer Receiver loops Note: OEM immobilizer receiver is located loops on the underside of the steering column, where the ignition switch would normally be.

  • Page 13: Module Programming

    Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 13 Module Programming Refer to the LED Diagnostics section for more information and for troubleshooting purposes. Important Make all the required connections to the vehicle, as described in the wiring diagram(s) found in this guide, and double check to ensure everything is correct prior to moving onto the next step.

  • Page 14: Module Reset

    Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 14 Module Reset A module reset will only erase programming performed in the previous steps. All settings (firmware) and settings flashed to the module using the web config tool will not be affected.

  • Page 15: Feature And Option List

    Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 15 Feature & Option List It is recommended to configure all the features and options listed below using the configuration tool found on the module flashing page on www.directechs.com. The web offers more options; however, manual configuration of the features is possible using the information on this page.

  • Page 16: Led Diagnostics & Troubleshooting

    Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 16 LED Diagnostics & Troubleshooting Description Troubleshooting Module Programming Make sure the D2D harness is connected or that the 12 Volt is Module has no power. present between the red and black wires. If the 12 Volt is present, the module may be defective.
  • Page 17 Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 17 Description Troubleshooting External module synchronization The diagnostic data bus was not detected, therefore the OBDII feature is not supported. (Flashes red, SmartStart features will be limited. red then orange) x 10 Activation Ground When Running (Status) Flashes Ground When Running (Status) command received.

  • Page 18: Limited One-Year Consumer Warranty

    Platform: DBALL2 Firmware: VW09 Rev.: 20170427 Page 19 Limited One Year Consumer Warranty For a period of ONE YEAR from the date of purchase of a Directed Electronics remote start or security product, Directed Electronics. (“DIRECTED”) promises to the original purchaser, to repair or replace with a comparable reconditioned piece, the security or remote start accessory piece (hereinafter the “Part”), which proves to be defective in workmanship or material...

  • Page 19: Quick Reference Guide

    Quick Reference Guide DBALL2-VW09 Vehicle Takeover with Get In and Go* Pit Stop Mode The Pit Stop Mode feature is practical when you need to stop and run an errand, Close the vehicle doors, hood and trunk, then press but wish to keep the engine running.
