Brocade DCX-4S Backbone Technical Specifications
Serial port specifications (pinout mini-USB)
Pin
1
2
3
4
5
Serial port specifications (pinout RJ-45)
Pin
1
2
3
4
5
6
7
8
Serial port specifications (protocol)
Parameter
Baud
Data bits
Parity
Stop bits
Flow control
130
Signal
+5V
UART0_TX
UART0_RX
IN
GND
Signal
Not supported
Not supported
UART1_TXD
GND
GND
UART1_RXD
Not supported
Not supported
Value
9600
8
None
1
None
Brocade DCX-4S Backbone Hardware Installation Guide
Description
Not used
Debug port
Console port
Not used
Ground
Description
N/A
N/A
Transmit data
Logic ground
Logic ground
Receive data
N/A
N/A
