a) Position one of the transceivers so that the key is oriented correctly to the port and insert the
b) Select the cable that corresponds to the port and position it so that the key (the ridge on one side
c) Repeat Step a and Step b for the remaining ports.
d) Organize the cables as required.

Verifying correct configuration of the fabric

Copying the command outputs from this section into a file is recommended.
1. Create an "after" SAN profile by entering the following commands and copying the output to a text file
named SANafter.txt:
• nsShow
• nsAllShow
• switchShow
• fabricShow
• lscfg --show (if using the Vvirtual Fabric feature)
switch:admin> nsshow
Type Pid
N
<output truncated>
switch:admin> nsallshow
{
020f00 021fda 021fdc 021fe0 021fe1
5 Nx_Ports in the Fabric}
switch:admin> switchshow
switchName: rsl8-st03-dcx-01
<output truncated>
switch:admin> fabricshow
Switch ID Worldwide Name Enet IP Addr FC IP Addr Name
<output truncated>
switch:admin>lscfg --show
Created switches: 128(ds) 1 2(bs)
Port
-------------------------------------------------------------------
FID
<output truncated>
switch:admin>
2. Determine any differences between the information in the SANafter.txt file and the information in the
SANbefor.txt file created earlier. In particular, look for differences in the following:
• Device types
• Number of devices
• ISL and port states
• Number of switches in the fabric
3. Resolve any issues or unintentional changes to the Brocade DCX-4S or fabric:
• If there are any mechanical problems, try reseating the associated component.
• If the configuration information is not correct for the Brocade DCX-4S, modify as required.
• If other issues exist, contact your support provider.
Brocade DCX-4S Backbone Hardware Installation Guide
53-1001191-15
transceiver into the port until it is firmly seated and the latching mechanism clicks.
of the cable connector) is aligned with the slot in the transceiver. Insert the cable into the
transceiver until the latching mechanism clicks.
ATTENTION
Do not route cables in front of the air exhaust vent (located on the upper port side of the chassis).
Air exhaust vents are also located on the lower port side if the Port Side Exhaust Kit is installed.
COS PortName NodeName TTL(sec)
020f00; 3;10:00:00:01:73:00:29:46;10:00:00:01:73:00:29:46; na
Fabric Port Name: 20:0f:00:60:69:90:03:f0
0 1
1 | 1 | 1 | 1 | 1 | 128 | 128 | 128 | 128 | 128 |
Verifying correct configuration of the fabric
2 3 4 5 6 7 8 9
