MaINTENaNcE

FILTER CLEANING INSTRUCTIONS
This faucet is provided with one stainless steel filter preventing foreign particles to enter
the lines. It is recommended to clean the filter every six (6) months. If the water flow has
decreased, this can be because the filter is clogged. The filter can be cleaned as follows:
1. Shut-off the water shut off valve (angle valve).
2. Remove the filter located between the solenoid valve housing and the inlet adapter \
shut off valve.
3. Wash the filter under running water.
4. Reassemble the parts.
5. Make sure that there is no water leakage.
CARE AND CLEANING OF ChROME AND SpECIAL FINIShES
DO NOT use steel wool or cleansing agents containing alcohol, acid, abrasives, or the like.
Use of any prohibited cleaning or maintenance products or substances could damage the
surface of the faucet. For surface cleaning of faucet use ONLY soap and water, then wipe dry
with clean cloth or towel. When cleaning bathroom tile, the faucets should be protected
from any splattering of harsh cleansers.
SOLENOID VALVE SERVICING
The solenoid valve diaphragm requires periodical cleaning every six (6) months. Remove
the diaphragm from the solenoid valve and examine it for dirt. in case it is dirty or clogged,
wash it under running water and reassemble it.
Do not attempt to dismantle the solenoid valve if you are unfamiliar with electronic
solenoid valves.
12
sParE ParTs lIsT
SEALS & SCREWS KIT DOLphIN FB/FE
SEALS & SCREWS KIT DOLphIN 1000FB/1000FE
10-pACK SENSOR KIT DOLphIN FB/FE
10-pACK SENSOR KIT DOLphIN 1000FB/1000FE
10-pACK SOLENOID VALVE KIT
INSERT KIT DOLphIN FB/FE
INSERT KIT DOLphIN 1000FB/1000FE
8-pACK SOLENOID hOUSING KIT DOLphIN FB/FE
SpOUT KIT DOLphIN FB/FE
SpOUT KIT DOLphIN 1000FB/1000FE
NIppLE KIT DOLphIN 1000FB/1000FE
hANDLE KIT DOLphIN 1000FB/1000FE
MIxER hANDLE KIT DOLphIN 1000FB/1000FE
BATTERY BOx FOR 9V BATTERY
12-pACK 9V TRANSFORMER (EU pLUG)
REMOTE CONTROL 13B (OpTIONAL)
SOAp & WATER REMOTE CONTROL (OpTIONAL)
07210099
07210100
07220430
07220362
07232000
07240006
07240028
07221119
07271035
07271016
07246007
07260013
07260012
06530080
06540002
07100005
07100014
