INsTallaTIoN
FOR TRANSFORMER VERSION:
a. Connect the waterproof
connector coming from
the electronic unit to the
transformer.
2
b. plug the transformer into the
electricity socket.
IMPORTANT: Wait 10 seconds before
operating the system.
If the range is unsatisfactory, refer to the section titled "Settings
3
adjustment".
This faucet includes a special
aerator that allows you to
adjust the water stream
direction on site in order to
prevent water splashing if
NOTE
needed. To change the angle of
the water stream, simply move
the adjustable tilting plate by
pressing it smoothly.
8
from the electroNic uNit to the traNsformer
SECONDS

sETTINgs aDjusTMENT

DETECTION
RANGE
DELAY IN TIME
SECURITY TIME
COMFORT FLUSh
Adjusting the settings with the remote control
If necessary, the sensor settings can be adjusted as following:
Shut off the water supply. In order to adjust the sensor with the remote control, hold the
remote control straight in front of the sensor in a distance of about 6-8" (15-20cm). Choose
the function you want to adjust by pressing once on one of the function buttons. After
pressing once on a specific function button, a quick flashing of the LED at the front of the
sensor will occur. At this stage, you can change the setting by pressing the (+) or the (-)
buttons, every push will increase or decrease one level. After finishing the adjustment, turn
the water supply back on.
DETECTION RANGE: Only if necessary, use the remote control to adjust the
sensor range as follows:
press the RANGE button. Wait until a quick flashing of the LED in the sensor
eye is perceived. Then, press + to increase the one level and – to reduce it
every push will increase or decrease one level.
NOTE: Once you have changed the detection range with the remote control, this
distance will be remembered by the sensor, even if the power source is disconnected.
DELAY OUT TIME
TEMpORARY OFF
FUNCTION
RESET
hYGIENE FLUSh
