Stern Engineering DOLPHIN F Series Installation And Maintenance Manual page 2

INDEX
1 TEChNICAL DATA
2-3 pACK CONTENTS
4 pRE-INSTALLATION INFO
5-8 INSTALLATION
9-10 SETTINGS ADJUSTMENT WITh REMOTE CONTROL
11 BATTERY REpLACEMENT (BATTERY MODELS ONLY)
12 MAINTENANCE
Filters cleaning instructions
Care and cleaning of chrome and special finishes
Solenoid valve servicing
13 SpARE pARTS LIST
14 LIMITED WARRANTY
15 TROUBLEShOOTING
TEchNIcal DaTa
DOLphIN FB 270170
DOLphIN FE
270180
Power supply:
9V battery or 9V transformer
0.5-8.0 bar (7-116 pSI)
Recommended water
With water pressure of more than 8 bars,
pressure:
use a pressure reducing valve for reduction.
Preset sensor range: 200 mm / 7.87" (customizable with optional remote control)
Minimum sensor range:
80 mm / 3.15"
Maximum sensor range: 300mm / 11.81"
Security time: 90 seconds (can be reduced with optional remote control)
Hot water temperature: Max 70˚C
DOLphIN 1000 FB 270320
DOLphIN 1000 FE
270330
1
