Lullaby
INTRODUCTION
ALTERNATING DYNAMIC PRESSURE THERAPY SYSTEM
Thank you for choosing a Sidhil Lullaby Alternating Dynamic Pressure
Therapy System. This user manual should be read carefully before you
use your mattress system as it contains important information regarding
safe operation and maintenance in order to provide long lasting and reliable
service.
Please ensure that you understand all the instructions, if you have any
questions concerning the operation and maintenance of the mattress
system please contact your supplier who will provide you with expert
professional advice.
The Lullaby Alternating Dynamic Pressure Therapy System is intended to
provide comfort and pressure relief to patients vulnerable to pressure
damage.
It is designed for use on the Sidhil Inspiration Cot.
Ideally,
patients allocated to this system will have some degree of independent
mobility or can be repositioned according to individual needs.
The standard system DYN/TRIO/LULL incorporates an alternating mattress
with static head section. An optional system DYN/TRIO/LULL/RP
incorporates an alternating mattress with alternating head section
The maximum patient weight limit is 160kg (25 stone).
WARNING
Misused electrical equipment can be hazardous.
Accessories that have not been approved or designed for use
with the system should not be used.
This electrically operated system should not be used in the
presence of flammable gases or in operating theatres.
This product is not recommended for carrying patients during
emergency evacuation.
In line with our policy of continuous improvement we welcome any
suggestions that could lead to product improvement.
This product is manufactured to comply with the essential
requirements of the Medical Devices Directive 93/42 EEC
User Instructions
www.sidhil.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lullaby and is the answer not in the manual?

Questions and answers

Related Manuals for sidhil Lullaby

Summary of Contents for sidhil Lullaby

  • Page 1 Lullaby INTRODUCTION ALTERNATING DYNAMIC PRESSURE THERAPY SYSTEM Thank you for choosing a Sidhil Lullaby Alternating Dynamic Pressure Therapy System. This user manual should be read carefully before you use your mattress system as it contains important information regarding safe operation and maintenance in order to provide long lasting and reliable service.

  • Page 2: Table Of Contents

    Contents SECTION 1 GETTING STARTED SECTION 1 GETTING STARTED ............3 Parts list 1.1 Parts list ................... 3 The transport carton contains everything you need to use your mattress. This includes: 1.2 Setting up mattress and power unit on a bed frame ......4 1.3 Switching system on and basic operation........

  • Page 3: Setting Up Mattress And Power Unit On A Bed Frame

    *If the bed does not have a foot board, place the power unit on the floor with the front of the unit facing upwards. Ensure the rear of the unit is Setting up mattress and power unit on a bed frame not obstructed by carpet, rugs etc it is advisable to place the unit on a firm surface.

  • Page 4: Switching System On And Basic Operation

    3. Once inflated, ensure that the mattress is correctly position on the bed. please contact your local authorised service personnel or Sidhil Ltd Keep the mains lead away from warm surfaces 4.

  • Page 5: Power Unit Operation

    Having established a base-line, pressure can be increased to provide added support for the semi-recumbent (sitting up) patient. SECTION 2 POWER UNIT OPERATION NOTE: Wait a minimum of 12 minutes between any pressure adjustment Normal operating mode and patient assessment. It will take a full cycle for the system to adjust to the new setting.

  • Page 6: Transport Mode

    To select static mode depress the dynamic/static switch to static , the orange and black connectors. The two single pipes snap fit into the dual static light will now be illuminated amber (see Figure 8). connection pipes as shown in Figure 9. The pressure can be adjusted to suit using the pressure adjustment dial on Fig 9: Connecting pipes for transport mode the front of the power unit.

  • Page 7: Alarms

    minutes back to its original pressure setting. Note: Until the system re- A persistent alarm light indicates a system fault. In this instance see the inflates to the desired pressure the red alarm light will be illuminated. Simple fault finding section. SECTION 3 ALARMS SECTION 4...

  • Page 8: Simple Fault Finding

    2. Check that the dynamic/static Mattress is not alternating rocker switch is set to dynamic 3. Check mattress is not in transport mode If the above actions fail to rectify the problem please contact your local authorised service personnel or Sidhil Limited.

  • Page 9: Servicing

    The mattress serial number is located on a label inside the mattress This service can be supplied by Sidhil technicians or alternatively Sidhil can at the foot end just above the umbilical entry. The label is sewn into the provide appropriate training.

  • Page 10: Technical Specifications

    Power unit: 230V, 50Hz, 0.2A SECTION 7 TECHNICAL SPECIFICATIONS Supply Voltage Power down alarm: 24~250VAC, 50Hz, 0.01 - 6A Mains plug: 3A Mattress Fuse Rating Power unit: 1A (x2) 1290mm x 695mm x 100mm Power Rating 12VA Dimensions (51 x 27.5 x 4 ) Conforms to EN 60601.1:1996, UL2601 - Electrical Safety Weight...

  • Page 11: Warranty

    Sidhil Ltd guarantees this product is free from defects in material and workmanship under normal use for two (2) years from the date of purchase from Sidhil Ltd and its subsidiary companies or its authorised dealers. All implied warranties, including but not limited to those implied warranties of fitness and merchantability, are limited in the total duration of two years from date of purchase.
