Parts List - Linear Technology DC1699A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
DC1699A Genreral BOM
1 1 C1
2 1 C2
3 1 C5
4 1 C7
5 3 E1, E2, E6
6 5 E3-E5, E9, E10
7 1 LED2
8 1 R1
9 1 R2
10 2 R3, R10
11 1 R5
12 2 R6, R7
13 1 R8
14 1 R11
15 0 R14
16 2 R15, R17
17 1 U2
DC1699A-A
1 1 DC1699A
2 1 C4
3 1 JP1
4 1 JP1
5 1 R4
6 1 R9
7 2 R12, R18
8 1 R13
9 1 SW1
10 1 U1
11 1 U3
12 1 U4
DC1699A-B
1 1 DC1699A
2 1 U1
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
Capacitor, 1μF 20% 1206 100V X7R
Capacitor, 0.47μF 20% 0603 16V X5R
Capacitor, 0.1μF 10% 0402 16V X5R
Capacitor, 0.1μF 10% 0603 100V X7R
TURRET TERMINAL
TURRET TERMINAL
RED1206 LED
Resistor, 1.69k 1% 0603 1/16W
Resistor, 806 1% 0603 1/16W
Resistor, 10k 5% 0402 1/16W
Resistor, 1k 5% 0603 1/16W
Resistor, 100 1% 0603 1/16W
Resistor, 13.7k 1% 0402 1/16W
Resistor, 0.1Ω 1% 2512 2W
OPTIONAL
Resistor, 0Ω 0603 1/16W
IC, LT3010EMS8E#PBF
GENERAL BOM DC1699A
Capacitor, 0.1μF 20% 0402 10V X5R
HEADER, 3-PIN
SHUNT
Resistor, 124k 1% 0402 1/16W
Resistor, 249k 1% 0402 1/16W
Resistor, 1M 1% 0402 1/16W
Resistor, 392k 1% 0402 1/16W
Switch, push button
IC, LT6108IMS-1
IC, LTC6993CS6-1#PBF
IC, LTC6991CS6#PBF
GENERAL BOM DC1699A
IC, LT6108IMS-2
DEMO MANUAL DC1699A
MANUFACTURER/PART NUMBER
AVX 12061C105MAT2A
AVX 0603YD474MAT2A
AVX 0402YD104KAT2A
Murata/GRM188R72A104KA35D
Mill Max 2501-2-00-80-00-00-07-0
Mill Max 2308-2-00-80-00-00-07-0
Panasonic/LN1251C
VISHAY/CRCW06031K69FKEA
VISHAY/CRCW0603806RFKLEA
VISHAY/CRCW040210K0JNED
VISHAY/CRCW06031K00JNEA
VISHAY/CRCW0603100RFKEA
VISHAY/CRCW040213K7FKED
IRC/LR2512LF-01-R100-F
VISHAY/CRCW06030000Z0EA
Linear Technology Corp.LT3010EMS8E#PBF
TDK/C1005X5R1A104M
SAMTEC TSW-103-07-L-S
SAMTEC SNT-100-BK-G
VISHAY/CRCW0402124KFKED
VISHAY/CRCW0402249KFKED
VISHAY/CRCW04021M00FKED
VISHAY/CRCW0402392KFKED
Panasonic/EVQPPDA25
Linear Technology Corp. LT6108IMS-1
Linear Technology Corp. LTC6993CS6-1#PBF
Linear Technology Corp. LTC6991CS6#PBF
Linear Technology Corp. LT6108IMS-2
dc1699af
5
