  • Page 1 Camera Manual S26 Flex...
  • Page 2 Copyright © 1999-2019, MOBOTIX AG, Langmeil, Germany. Technical information subject to change without notice. MOBOTIX AG and its subsidiaries do not assume any liability for technical or editorial errors or omissions contained herein.

  • Page 3: Table Of Contents

    1.5.3 Ethernet Patch Cable for Bayonet Catch 1.5.4 NPA-PoE-Set 1.5.5 MX-Overvoltage-Protection-Box 1.5.6 MX-NPA-Box 1.5.7 MX-GPS-Box 1.5.8 MX-232-IO-Box 1.5.9 ExtIO Expansion Module 1.5.10 Mx2wire+ Media Converter 1.5.11 AudioMount 1.5.12 SpeakerMount 1.5.13 Other Accessories 1.6 MOBOTIX Software 1.6.1 Integrated Camera Software (Firmware) 1.6.2 MxManagementCenter 1.6.3 MOBOTIX MxBell...
  • Page 4 Preparing the Installation Before Mounting 2.2.1 Overview of Cable Connections 2.2.2 Notes on Cable Lengths and Power Supply 2.2.3 Network Connection with MOBOTIX Patch Cable 2.2.4 Network Connection with Installation Cable 2.2.5 Using the MiniUSB Cable 2.2.6 Using MxBus Modules 2.2.7 External Audio Support (Microphone/Speaker)
  • Page 5 3.4.2 Formatting the MicroSD Card 3.4.3 Activating Recording 3.4.4 Accessing Data on the MicroSD Card 3.4.5 Deactivating Card Recording 3.4.6 Using a MicroSD Card in a Different MOBOTIX Camera 3.4.7 Limitations on Warranty When Using Flash Storage Media 3.5 Configuration in the Browser 3.5.1 Overview...

  • Page 6: Safety Warnings

    S26, the recording of video and sound data may be subject to special documentation or it may be prohibited. All users of MOBOTIX products are therefore required to familiarize themselves with all applicable regulations and to comply with these laws. MOBOTIX AG is...

  • Page 7: Notes On System Security ("Cyber Security")

    • Notification threshold: 10 • Timeout: 60 Minutes • Block IP Address: √ For more information on this topic, please read the «Cyber Protection Guide» on www.mobotix.com (under Support > Download Center > Documentation > Brochures & Guides > Cyber Security).

  • Page 8: Foreword

    If you have any questions, our support and international sales staff are available at intl-support@mobotix.com from Monday to Friday, 8 am to 6 pm (German time). We would like to thank you for your trust and wish you all the best with your new MOBOTIX camera S26 Flex!
  • Page 9 S26 – camera with one hemispheric image sensor for concealed installation behind walls or over ceilings 180°-Panorama...

  • Page 10: Product Overview

    S26 Camera Manual: Product Overview PRODUCT OVERVIEW S26 – Lenses, Hardware, Image Formats Lenses, Sensors B016 Hemispheric • B036 Superweitwinkel – B041 Superweitwinkel – B061 Weitwinkel – B079 Weitwinkel – B119 Tele – B237 Tele – B500 Tele – CSVario 4.5 bis 10 mm –...

  • Page 11: S26 - Software Features

    MX-232-IO-Box Programming interface/HTTP API • Security features (HTTPS/SSL, IP-based access control, IEEE • 802.1X network authentication) Video Analysis Video Motion detector • MxAnalytics • MxActivitySensor • Video Management Software Free-of-charge download MxManagementCenter • from www.mobotix.com MOBOTIX MxBell • or App Store/Google Play...

  • Page 12: S26 - Technical Data

    Mx-S26A/B*-6D016 (daylight image sensor, color) Mx-S26A/B*-6N016 (night image sensor, Black&White) Model Variants *Variant Mx-S26B supports MOBOTIX MxBus modules Lens Option B016 (focal length 1.6 mm, f/2.0, image angle 180°x180°) Color sensor (daylight): 0,1 lx @ 1/60s; 0,005 lx @ 1s Sensitivity Black&White sensor (night): 0,02 lx @ 1/60s;...
  • Page 13 S26 – Technical Data User/group management, HTTPS/SSL, IP address filter, IEEE 802.1x, intru- Security sion detection, digital image signature, MxFFS EN 55032:2012, EN 55024:2010, EN 50121-4:2015, FprEN 61000-6-1:2015, EN 61000-6-2:2015, EN 61000-6-3:2007+A1:2011+AC:2012, EN 61000-6- Certifications 4:2007+A1:2011, EN 50581:2012, EN 60950-1:2006+A11:2009+A1:2010+ A12:2011+A2:2013, E13*10R05/01*14649*00, 47 CFR Part 15B, AS/NZS CISPR32:2015 Power Supply...

  • Page 14: S26 - Delivered Parts And Dimensions

    S26 Camera Manual: Product Overview S26 – Delivered Parts and Dimensions 1.4.1 The S26 Camera M.10 8.10 8.11 8.13 8.12...
  • Page 15 S26 – Delivered Parts and Dimensions Item Number Part Name Camera housing (with base plate) Lens L10 (6MP)/L12 (5MP) (installed) Dome (installed) Housing cover for S15M (installed) Stainless steel flat-head Allen screw M4x8 (installed) Washer Sealing plug, blue, small (sensor modules, USB, inserted) Sealing plug, blue, large (Ethernet patch cable, installed) Cable retainer with bayonet catch (Ethernet patch cable, installed) Single wire plug, white (Ethernet installation cable, microphone, speaker,...
  • Page 16 S26 Camera Manual: Product Overview S26 Camera Housing The MOBOTIX S26 consists of a base plate for attaching the camera, a housing with built-in lens, and a housing cover. LED default settings: MicroSD card Power (on), Error (flashing) Recording (flashing)
  • Page 17 S26 – Delivered Parts and Dimensions Internally Accessible Connections of the S26 The MOBOTIX S26 provides the following internal connections that can be accessed once the cover plugs and housing cover are removed: LSA+ terminal Ethernet installation cable Screw terminals...
  • Page 18 S26 Camera Manual: Product Overview Dimensions S26 The drilling templates are available from www.mobotix.com, 115 mm/4.53 in Support > Download Center > Documentation > 100 mm/3.94 in Drilling Templates Always print or copy drilling template in their original size! Diam. 5.5 mm/ 0.22 in...
  • Page 19 S26 – Delivered Parts and Dimensions 48 mm/1.89 in 39.5 mm/1.56 in 33.5 mm/1.32 in 5 mm/ 0.2 in Attaching the Camera Housing Slots M6 threaded holes...

  • Page 20: Available Accessories

    No.: MX-CBL-MU-STR-05/2/5 (Straight/Straight) on the camera only Order No.: MX-CBL-MU-EN-STR-05/2/5 (Straight/Angled) With this cable, which is up to five meters long, MOBOTIX add-on modules (MX-232-IO-Box, ExtIO, CamIO) can be connected directly to the S26. 1.5.2 MiniUSB Cable to USB a Socket Order No.: MX-CBL-MU-STR-AB-05/2/5...

  • Page 21: Mx-Overvoltage-Protection-Box

    Weatherproof network connector (protection class IP65, –30 to 60 °C/–22 to 140 °F) with surge protec- tion of up to 4 kV for MOBOTIX IP cameras , ideal for replacing the MX-Patch-Box. At the same time, the MX-Overvoltage-Protection-Box provides a weatherproof connection of a camera’s patch cable to a network patch...

  • Page 22: Mx-232-Io-Box

    D-Sub 15-HD connector. The MX-232-IO-Box can be connected as an add-on module to all MOBOTIX cameras with an MxBus or USB interface. The maximum length of the MxBus cable (diameter: 0.8 mm) is 50 m. If the MiniUSB connection is used, the maximum cable length is 5 m.

  • Page 23: Audiomount

    Together with the AudioMount and additional MOBOTIX accessories, you can easily set up the S26 Flex as a hemi- spherical door station (note that the camera needs to run a firmware 4.1.9 or higher).

  • Page 24: Other Accessories

    S26 Camera Manual: Product Overview 1.5.13 Other Accessories Since the range of accessories for the MOBOTIX system keeps growing, you will find the list of applicable accessories in the Camera Configurator on the MOBOTIX website www.mobotix.com. THE MOBOTIX INFORMATION CHANNELS Support on the MOBOTIX Website www.mobotix.com/en/support...

  • Page 25: Mobotix Software

    The MOBOTIX MxBell for iOS and Android devices (iOS 11/Android 5.0 and higher) is also available free of charge from the App Store/Google Play for your mobile applications.

  • Page 26: Mxmanagementcenter

    MxManagementCenter is perfectly designed in combination with MOBOTIX cameras repre- senting the decentralized concept at its best. MxMC allows controlled recording access via the camera or later directly to the NAS.

  • Page 27: Mobotix Mxbell

    Never miss another visitor, thanks to push notifications! Use MOBOTIX MxBell on your smart- phone or tablet to receive notifications from the doorbell of a MOBOTIX IP Video Door Station and live views from MOBOTIX cameras. This app helps you open the door and enables hands- free talking, automatic camera search, a live view, camera connection via SSL and display of the connection status.

  • Page 28: Installation

    S26 Camera Manual: Installation INSTALLATION Like all MOBOTIX cameras, the S26 is extremely flexible in terms of how and where it can be installed. An S26 can be used for both indoor and outdoor applications. In fixed or mobile applications – constantly changing locations or in/on vehicles of any kind. The S26 cameras are weatherproof according to IP66 and can work reliably in temperatures ranging from –40 to 60 °C/–40 to 140 °F without extra housing, heating or fan.

  • Page 29: Preparing The Installation

    5. What cabling considerations are necessary? The following sections contain answers to each of these questions. If you have more detailed questions,please ask your MOBOTIX partner directly or contact the MOBOTIX support. To find the contact data, please open www.mobotix.com and the Support section.

  • Page 30: Before Mounting

    2.2.1 Overview of Cable Connections The following cables can be used with the S26 (see also Section 1.5, «Available Accessories»): MOBOTIX patch cable : This supplied MOBOTIX cable is designed for direct connection to • the MX-Patch-Box , the MX-NPA-Box or a standard network port (only in indoor areas).
  • Page 31 Additional cable or net- work installation cable Caution Only MOBOTIX cables may be used for the Ethernet and USB connection as well as to the sensor modules (S26) to ensure the camera remains permanently watertight. MiniUSB Ethernet...

  • Page 32: Notes On Cable Lengths And Power Supply

    • Power is supplied to the camera via the camera Ethernet connection (patch or installation cable). We recommend using a MOBOTIX PoE adapter or another similar high-quality PoE product to loop-in the power supply: – One camera: with the PoE adapter (MX-NPA-PoE or MX-NPA-Box) –...

  • Page 33: Network Connection With Mobotix Patch Cable

    For more information on changing the PoE class, please see Section 2.4.7, «Variable PoE»). 2.2.3 Network Connection with MOBOTIX Patch Cable The supplied MOBOTIX patch cable can be used to connect the camera to an MX-Patch-Box , an MX-NPA-Box or to a standard network port.

  • Page 34: Network Connection With Installation Cable

    The opening provided for the installation cable must be used for all other cables that are connected to the camera when using the MOBOTIX patch cable. Depending on the cable used, the single wire plug installed must be replaced with one of the Further cables other cable plugs (M.4/5).

  • Page 35: Using Mxbus Modules

    Before Mounting 2.2.6 Using MxBus Modules The MxBus camera connector is located under the housing cover (clamps 5 and 6 of the screw clamps) and allows the operation of additional modules for expanding functionality (e.g. connection of an MX-GPS-Box for determining time and position).

  • Page 36: Replacing The Microsd Card

    • Potentially a power drill and 6-mm drill bit for screw anchor holes for attaching the base plate. Drilling template for base plate (see www.mobotix.com, Support > Download Center > • Documentation > Drilling Templates). Scissors to cut out the template.

  • Page 37: Preparatory Steps

    2.2.10 Preparatory Steps Make sure of the following before starting to install the camera: Connection with MOBOTIX patch cable : The network connector has been guided either • with an MX-Patch-Box, an MX-NPA-Box or a standard network port (only permitted in indoor areas) into the vicinity of the mounting position of the camera.

  • Page 38: Installing The S26 Flex

    Connection, Additional Cables». 2.3.2 Attaching the S26 Camera Housing Use the drilling template available from www.mobotix.com, Support > Download Center > Documentation > Drilling Templates to mark the position of the drilling holes for the cam- era. Make sure that it is not scaled down when printing or copying the drilling template.
  • Page 39 Installing the S26 Flex Attachment to a Rear Wall If the S26 is attached with the base plate on a rear wall (and then, for example, to a separate stainless steel cover), the camera can be mounted in just a few steps: 1.

  • Page 40: Network And Power Connection, Additional Cables

    Center > Documentation > User Manuals > Accessories > Interface Boxes. Insert the MOBOTIX patch cable of the S26 into the network port for standard connections (only permitted in indoor areas). If additional cables are required inside the housing (MxBus, microphone, speaker), they must...

  • Page 41: Network Cabling For S26 With Installation Cables

    Network and Power Connection, Additional Cables 2.4.2 Network Cabling for S26 with Installation Cables 1. Remove housing cover and cable plugs : Loosen the Allen screw on the housing cover of the S26 and remove it. Push the cable plug in the camera out of the housing from the inside to the outside (red arrow).
  • Page 42 S26 Camera Manual: Installation Caution Make sure that all cable end offcuts are removed from inside the camera . If not, this could lead to short circuits ! Hint : Hold the cable ends firm before cutting them with the LSA+ tool. Only use the LSA/ Krone blade and set to LOW impact!

  • Page 43: Connecting Additional Cables

    Network and Power Connection, Additional Cables 2.4.3 Connecting Additional Cables Additional cables can be fed through the free opening in the housing, depending on the Ethernet connector used (patch cable or installation cable). If an installation cable is used, additional cables should be installed after the installation cable has been fitted. Ethernet via Patch Cable Ethernet via Installation Cable Additional cables...

  • Page 44: Power Supply Using A Switch

    For the S26 you should use (MX-NPA-PoE) the blue MX-NPA-PoE-Set Switch/router Power supply unit or the MX-NPA-Box – pre- vious MOBOTIX network power accessories, such as the NPA-Set, Power- Box and Power-Rack Camera (MX-NPA-Set, MX-NPR-4 RJ45 and MX-NPR8/20) are not...

  • Page 45: Power Supply When Connected Directly To A Computer

    Power supply unit ing to a computer For the S26 you should use the blue MX-NPA-PoE-Set or the MX-NPA-Box – pre- Camera vious MOBOTIX network (10.8.0.11/255.0.0.0) RJ45 power accessories, such as the NPA-Set, Power- Box and Power-Rack (MX-NPA-Set, MX-NPR-4 and MX-NPR8/20) are not...

  • Page 46: Variable Poe

    S26 Camera Manual: Installation 2.4.7 Variable PoE The power consumption of the camera depends on the functions in use as well as any periph- eral devices connected (see table). PoE classes 1, 2 or 3 may be selected in the browser-based user interface in order to optimally adjust the camera to your system design (PoE switch in use, emergency power concept, etc.).
  • Page 47 Notes...

  • Page 48: Operating The Camera

    S26 Camera Manual: Operating the Camera OPERATING THE CAMERA Manual and Automatic Operation MOBOTIX cameras do not require any extra software. Thus, you can set up and operate the Download the free-of-charge MxManagementCenter soft- MOBOTIX camera using a JavaScript-enabled browser on all common operating systems ware at www.mobotix.com...
  • Page 49 Manual and Automatic Operation • Network with fixed IP addresses In order to access the camera, it must have an IP address within the range of the local network. To set the camera’s network parameters, you can use one of these methods: –...

  • Page 50: First Images And The Most Important Settings

    S26 Camera Manual: Operating the Camera First Images and the Most Important Settings Once the MOBOTIX camera has been connected to the network, you need to set up the camera’s network interface accordingly. This step involves setting up and checking the network parameters of the camera.
  • Page 51 First Images and the Most Important Settings Windows 8.1/10: 1. Open Start > Settings > Control Panel > Network Connections. Clicking on Properties opens the dialog box shown. 2. Double-click on Internet Protocol (TCP/IP). On the General tab, activate the Use the following IP address option.
  • Page 52 2. Set Up the Target Network Parameters of the MOBOTIX Camera: 1. Open a web browser on the computer and enter the default IP address of the MOBOTIX camera in the address bar of the browser (for example, 10.8.0.99). Pressing Enter displays the user interface of the MOBOTIX camera (see also Section 3.2.2, «First Images...

  • Page 53: First Images And The Most Important Settings In The Browser

    3.2.2 First Images and the Most Important Settings in the Browser Once the MOBOTIX camera has been connected to the power supply and to the network, you can access the user interface with the live camera image in the web browser. Internet Explorer, Firefox, Safari or any other graphical browser with activated JavaScript is suitable.
  • Page 54 S26 Camera Manual: Operating the Camera Camera Views: Live, Player, MultiView The MOBOTIX camera automatically displays the live screen when it starts up (factory default set- ting). You can set a different start page in Admin Live view: http://<camera IP>/ Menu >...

  • Page 55: First Images And Network Parameter Configuration In Mxmc

    MOBOTIX cameras. The number of found cameras is shown next to the Add button. This number is updated automatically if the number of MOBOTIX cameras on the network has changed (i.e., by connecting new/disconnecting existing cam- eras)..
  • Page 56 Reconfiguring Network Addresses of Cameras Using Bonjour*, MxManagementCenter finds not only cameras on the same network as your computer, but also MOBOTIX cameras located in other subnets (status: ). In such a case, you would not be able to establish any connection to cameras in a different network or subnet.
  • Page 57 . Move to the next page and click on Finish. For more information, see the MxManagementCenter Tutorial, which can be downloaded as a PDF file from the MOBOTIX website: www.mobotix.com > Support > Download Center > Documentation > Brochures & Guides > Tutorials.

  • Page 58: Start Options Of The Camera

    S26 Camera Manual: Operating the Camera 3.2.4 Start Options of the Camera By default, the camera starts as DHCP client and automatically tries to get an IP address from a DHCP server. To start the camera in a mode different from the default mode, you can activate the boot menu of the camera.
  • Page 59 First Images and the Most Important Settings Starting the Camera with Factory Default (Network) Settings If you use the camera’s start option 2 to load the factory configuration, this configura- tion is not automatically saved in the camera’s flash memory. When the camera is next rebooted without using start option 2, the last stored configuration will be used.

  • Page 60: Virtual Ptz And Full Image Recording

    S26 Camera Manual: Operating the Camera Virtual PTZ and Full Image Recording 3.3.1 Preparing the Virtual PTZ Function The virtual PTZ function allows you to use a mouse or joystick to continuously zoom in on images from the selected video source and ”virtually” move the enlarged image section within the entire image sensor area.
  • Page 61 Virtual PTZ and Full Image Recording Operation Using USB Joystick A standard USB joystick can drastically improve vPTZ operation for the user – in the browser and in MxManagementCenter. Please first install the joystick on the PC according to the manufacturer’s instructions.

  • Page 62: Full Image Recording

    S26 Camera Manual: Operating the Camera 3.3.2 Full Image Recording It is possible to record a full image, regardless of the live image stream that is being displayed. This ensures that the recording always contains the full image of the lens used, even though the operator may have used the vPTZ features to zoom into the image in order to examine a specific detail.
  • Page 63 Virtual PTZ and Full Image Recording Activate/Deactivate Full Image Recording in the Browser To configure this feature, open the Setup Menu > Event Control > Recording dialog box and activate or deactivate the Full Image Recording option.

  • Page 64: Special Configuration In The Browser

    S26 Camera Manual: Operating the Camera 3.3.3 Special Configuration in the Browser Thanks to its hemispherical lens, the MOBOTIX S26 provides certain special configuration options for the image settings. Depending on where the camera is mounted (ceiling or wall) and on the live image display preferred by the user, certain important basic settings and, if necessary, their adjustment must be configured when a S26 is first installed.
  • Page 65 If the section meets your expectations, no further adjustment is necessary, and panorama configuration is complete. To change the image section to meet your specific expectations, continue with Step 2. Camera live image without MOBOTIX pan- orama correction with Quick Controls visible Note The currently visible image section may differ from the desired image section due to the installation position or any accessories in use, for example.
  • Page 66 S26 Camera Manual: Operating the Camera 2. Click on the lock icon. Clicking on the lock once opens it (lock clasp is raised). The lock prevents execution of later vPTZ actions, which could also unintentionally mod- ify the view you configure. This holds for all overview display modes, that is, also for Panorama/Focus, Double Panorama and Surround.
  • Page 67 Virtual PTZ and Full Image Recording Functions of the S26 OnScreen Control Close Tilt up Pan to the right Pan to the left Tilt down Zoom Panorama correction Image tilt correction Default setting To use the OnScreen Control, click on the arrows in the top area for shifting the image Depending on the mounting position (ceiling, wall, floor), section.
  • Page 68 S26 Camera Manual: Operating the Camera Ceiling-Mounted: Set North (User-Defined North Direction) Once the camera has been mounted on to the ceiling, you need to specify its North direction. This is not the ”true” direction of North but rather the main line of sight or the focus of the camera or sensor module.
  • Page 69 Virtual PTZ and Full Image Recording 3. In the Installation Quick Control, select the Set North option. 4. Store the desired North direction permanently by first activating the checkbox and then clicking on Yes. 5. You have now set the North direction for the Surround and Double Panorama display modes.
  • Page 70 Configuration of Audio Settings Thanks to the MOBOTIX S26 system’s flexible layout, there are a number of different micro- phone options depending on the model used (S26, S26). Information on how to connect external microphones and speakers is provided in Section 2.2.7, «External Audio Support (Microphone/Speaker)».

  • Page 71: Microsd Card Recording

    Admin Menu > Camera Status dialog box. Conservative Memory Usage Thanks to MOBOTIX MxFFS File System MxFFS formatting of the MicroSD card means that MOBOTIX camera software will use the flash device as evenly as possible, thus allowing for the maximum possible number of write/delete cycles.
  • Page 72 Monitoring The Cell Wear Of Flash Storage Devices (Patent Pending) MOBOTIX uses its own technology for this purpose and has a pending patent. You can view the flash wear in the status bar of the live image or by open- ing Admin Menu >...

  • Page 73: Formatting The Microsd Card

    / Flash Device Storage on External File Server / Flash Device): 1. Make sure that there is a MicroSD card in the card slot of the MOBOTIX camera. 2. Click Format in the SD Memory Card line. 3. Note down the characters shown in the Encryption password field or enter your own password.

  • Page 74: Activating Recording

    Storage on External File Server / Flash Device 1. Make sure that there is a MicroSD card in the card slot of the MOBOTIX camera. 2. Make sure that the MicroSD card is formatted in MxFFS format. 3. Activate the SD Flash Card option.

  • Page 75: Accessing Data On The Microsd Card

    In MxManagementCenter: Play back the recorded video sequences with audio by accessing the MicroSD card in the MOBOTIX camera via the camera or with a direct access to the MicroSD card via a card reader connected to the computer (coming soon).

  • Page 76: Using A Microsd Card In A Different Mobotix Camera

    S26 Camera Manual: Operating the Camera 3.4.6 Using a MicroSD Card in a Different MOBOTIX Camera A MicroSD card containing recorded video data from a MOBOTIX camera can be inserted into any MicroSD card-enabled MOBOTIX camera. Once a MicroSD card recording has been activated (requires a reboot), the ”new” MOBOTIX camera automatically synchronizes with the card and resumes recording.

  • Page 77: Configuration In The Browser

    HTTP commands using programs and scripts of the embedded software. The settings are stored in the camera’s flash memory. This section contains an overview of the basic browser settings of the MOBOTIX camera as well as further configuration options. Detailed information on the software functions is pro-...
  • Page 78 MOBOTIX camera. The camera can use either NTP time servers or Time Protocol servers. For more information on this topic, refer to the online help for the specific dialog boxes.

  • Page 79: General Browser Settings

    (Image Programs Quick Control). • Set the resolution of the live image: By default, all MOBOTIX cameras are factory-set to an image resolution of 640x480 pixels. You can select the desired resolution using the Resolution Quick Control.
  • Page 80 S26 Camera Manual: Operating the Camera • Set up actions/messaging: Upon detecting an event, the MOBOTIX camera can trigger alarms. These alarms can be adjusted to your needs and you can assign them to a specific event: playing back an alarm sound on the camera speaker, showing the visual alarm...

  • Page 81: Setting Up An S26 Flex As Door Station

    If you want to use a MOBOTIX S26 as door station, you should download the two manuals IP Video Door Station System Manual Part 1 and Part 2 (www.mobotix.com > Support >...

  • Page 82: Executing The Auto Configuration

    S26! The predecessor T24-DoorMaster (article no. MX-Door1-INT-PW) cannot be used with an S26. For installing and wiring these components, follow the same steps as for the MOBOTIX IP Video Door Station. You can find detailed information about wiring as well as the maxi-...

  • Page 83: Additional Notes

    5. Train the admin card. All three LEDs are now green. 6. Train the user cards as required. You can find detailed information on installing and operating the BellRFID module in the document BellRFID Quick Installation (www.mobotix.com > Support > Download Center > Documentation > Manuals). Finalize the Setup The most important functions of the door station are now available.

  • Page 84: Password For The Admin Menu

    S26 Camera Manual: Operating the Camera 3.7.2 Password for the Admin Menu Accessing the Administration Menu of the camera (Admin Menu softbutton) is only possible after entering a user name and password. Factory default user name is admin . • Factory default password is meinsm .

  • Page 85: Activating Event Control And Motion Detection

    Text and logos can be also deactivated or indi- and the MOBOTIX logo at the top of the image. Once the camera arming has been activated, vidually configured the text at the bottom of the live image (event, action, messaging and recording symbols) will also appear.

  • Page 86: Cleaning The Camera And Lens

    & Declarations of Conformity. 3.7.12 RoHS Declaration The products of MOBOTIX AG are in full compliance with Art. 5 of the German Electrical and Electronic Equipment Act and the E.U. Directive 2011/65/EU on the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment (RoHS) as far as they are subject to these regulations.

  • Page 87: Disposal

    Electrical and electronic products contain many reusable materials. For this reason, we would ask that you dispose of MOBOTIX products at the end of their service life in accordance with all legal requirements and regulations (or deposit these products at a municipal col- lection center).
  • Page 88 S26 Camera Manual Notes...
  • Page 89 VAT ID: DE202203501 You can fi nd the latest version of this and other documents (e.g., declarations of confor- mity) at www.mobotix.com in the Support > Download Center > Documentation > Manuals section. Technical specifi cations subject to change without notice!
