Mobotix S26 Flex Quick Install

Accessories

S26
AudioMount with integrated microphone and
speaker
(can, e.g., be used as an intercom solution)
• Mx6 system platform with H.264 support
• Includes MxAnalytics video analysis tools out-of-the-box
• Recording on internal MicroSD card (SDXC, SDHC installed)
• Audio connectors for microphone and speaker integrated
• Sensor for temperature integrated
• Weatherproof and robust camera housing (IP66, IK07)

S26 Standard Delivery

M.10
M.9
M.8
M.7
M.6
M.5
M.4
M.3
M.2
M.1
1.13
Standard Delivery
Item Count Part Name
1.1 1 Camera housing (with base plate)
1.2 1 Lens B016 (installed)

Mounting the Camera

1. Installation Using the Base Plate
Attach the camera using the supplied or other screws by affixing the base
plate to a suitable material
1
Note that you can also install the S26 behind faceplates of up to 6.4 mm/0.25 in
thickness using stud bolts
2
2. Installation With AudioMount (Accessory)
Using the self-adhesive AudioMount
intercom solution. This is explained in the product documentation «Quick
Install AudioMount» (suitable drilling template is supplied).
Notes:
• Due to the missing MxBus connection, this camera model cannot be installed as a fully-fledged door station with connected MxBus modules and
corresponding remote stations.
• For the realization of an intercom solution, switching inputs and outputs can be used via a USB-connected MX-232-IO-Box. In this case, the process-
ing of the switching input signals (e. g., from a bell) and the switching outputs (e. g., for a door release) is carried out internally via the available
standard mechanisms (e. g., events and network messages). Autoconfiguration and other door station functions are not available.

Connections and Initial Operation of the S26

You can find detailed information on the installation and connections of the S26 in the S15 Camera Manual for the S15M (PDF, available on
www.mobotix.com > Support > Manuals).
Please note that the boot options of this camera have changed compared to its predecessor (see «Boot Options of the S26» ) and the camera only has
one key ("L"). Regarding the rest of the initial operation of the S26, please see the S15 Camera Manual in Chapter 3, «Initial Operation» .
L
USB
Ethernet patch cable
In special situations, you can attach an external sensor module to the S26. In this case, you need to attach the external sensor module to the "Cam1"
connector of the camera; then follow the instructions for attaching sensor modules to the S16. After configuring the external sensor module, the inte-
grated image sensor of the S26 will be deactivated.

Inserting/Exchanging the SD Card

All camera models can use the integrated MicroSD card (SDHC) to record video data. In order to exchange the MicroSD
card, please proceed as outlined in the following instruction. For information on reliable SD cards, please see the MOBOTIX
website www.mobotix.com > Support > MxMedia Library > Planning in the document MicroSD Card Whitelist for
MOBOTIX Cameras .
When replacing the SD card, make sure that recording has been deactivated in the browser ( Admin Menu > Storage >
Storage on External File Server / Flash Device ; activate recording again in the same dialog).
1. Remove the SD card
Loosen the threaded plug at the top of the
housing (using a suitable coin, for example)
and remove the plug. Using tweezers, gently
press the SD card into the slot (as indicated by
the arrow) until you hear a click . The card is
protruding slightly and can be easily removed
with the tweezers.

Boot Options of the S26

By default, the camera starts as DHCP client and automatically tries to get
an IP address from a DHCP server. To start the camera in a mode different
from the default mode, you can activate the boot menu of the camera.
1. Preparing the Camera
• Disconnect the camera's power supply.
• Reconnect the power supply of the camera.
2. Activating the Boot Menu
The red LED lights up 5 to 10 seconds after establishing
the power supply and will stay on for 10 seconds. Briefly
press the key L indicated by the red circle in the figure.
The camera enters the boot menu, ready for selecting
one of the boot options.
The LED now flashes once and repeats the flash signal
after pausing for one second (the number of flashes indicates the current
boot option). To go to the next boot option, briefly press the key again
(< 1 sec). After the last boot option, the camera returns to the first option
(LED flashes once).
1.1
1.2
1.6
1.8
1.10
1.11
1.12
(see «Drilling Template» on page 2 ).
(see «Drilling Template» on page 2 ).
, you can install the S26 as an
3
LEDs
Key L
Housing cover
Lens
B016
Base plate
Ethernet installation cable,
LSA terminal block
Quick Install
S26 Flex
Hemispheric 6MP Camera with Day
or Night Image Sensor for Concealed
Installation
MOBOTIX 6MP camera for concealed installation in indoor
and outdoor applications, available as S26 Flex with lens
B016 and Day or Night image sensor.
More information:
www.mobotix.com > Products > Outdoor Cameras > Flex S26
Mx-S26
32.839-002_EN_09/2017
Item Count
1.3 1
1.4 1
1.5 3
1.6 1
1.3
1.7 1
1.8 1
1.9 1
1.4
1.10 1
1.11 1
1.5
1.12 1
1.13 1
1.7
Item Count
1.9
M.1 4
M.2 4
M.3 4
M.4 2
M.5 1
M.6 1
M.7 1
M.8 1
M.9 1
M.10 1
1
Microphone
Speaker
2. Insert the SD card
Again using tweezers, insert the SD card as
shown (contacts facing forward) into the card
slot. Make sure that you hear a click again when
pushing the card into the slot. The card is now
locked and can be used. Insert the threaded
plug again and tighten it using the coin.
LED Boot
flashes Option
1 x Not used
Factory
2 x
Defaults
Automatic
3 x
IP Address
Recovery
4 x
L
System
*Only on cameras with audio option and installed speaker.
3. Selecting a Boot Option
Press the key longer (> 2 sec) into the hole. The camera confirms the selec-
tion by flashing rapidly three times. After 20 sec, the camera will confirm
the selection by playing a sound according to the table above.
If nothing is selected, the camera will resume its normal boot process
after a certain time.
Standard Delivery
Part Name
Dome (installed)
Housing cover for S26 (installed)
Stainless steel Allen screw with flat head M4x8 mm (installed)
Sealing ring (installed)
Sealing plug blue, small (sensor modules, USB, mounted)
Sealing plug blue, large (Ethernet patch cable, mounted)
Cable lock with bayonet catch (Ethernet patch cable, mounted)
Eight-wire plug, white (Ethernet installation cable, microphone,
speaker)
MicroSD card pre-installed (SDXC)
Threaded plug for SD card, blue (mounted)
Ethernet patch cable, 50 cm/19.7 in with sealing
Mounting Supplies
Part Name
Stainless steel washers dia. 4.3 mm
Dowels 6 mm
Stainless steel wood screws with hex head 4x40 mm
Cable plug 5 to 7 mm, white (Ethernet installation cable)
Cable plug 3 to 5 mm, white (Ethernet installation cable)
Allen wrench 2.5 mm
Lens wrench (lens, dome)
Module wrench (sensor module, glass cover/filter insert)
Cable tie (Ethernet installation cable, microphone, speaker)
Screwdriver (terminals)
2
3
MOBOTIX patch cable or MiniUSB
additional cable
Additional cable or net-
work installation cable
Meaning
Not available on this camera model.
Starts the camera with factory defaults
(factory default IP address, users and
passwords will not be reset).
Starts the camera as DHCP client and
tries to obtain an IP address from a
DHCP server. If a DHCP server cannot
be found or no IP address can be
obtained, the camera starts with its
factory default address.
Starts the camera with the recovery
system, e.g., in order to recover from a
failed update of the camera software.
Cam1
Audio
Confirmation*
—
Boing
Boing Boing
Alarm Sound
