Target Headers and Connectors

4.3.1 Target Digital I/O
The J200 and J201 headers provide access to the ATmega328P digital I/O pins.
Table 4-1. J200 Digital I/O High Byte Header
J200 Pin ATmega328P Pin
1 PB0
2 PB1
3 PB2
4 PB3
5 PB4
6 PB5
7 GND
8 AREF
9 PC4
10 PC5
Table 4-2. J201 Digital I/O High Low Header
J201 Pin ATmega328P Pin
1 PD0
2 PD1
3 PD2
4 PD3
5 PD4
6 PD5
7 PD6
8 PD7
4.3.2 Board Power Header
The J202 header enables connection to the ATmega328P Xplained Mini power system.
Table 4-3. J202 Power Header
J202 Pin Signal
1 NC
2 VCC_TARGET
3 RESET_SENSE
4 VCC_P3V3
©
