4. Hardware User Guide
The following sections describe the implementation of the relevant peripherals, headers, and connectors on the
ATmega328P Xplained Mini and their connections to the ATmega328P. The tables of connections in the sections
below also describe which signals are shared between the headers and on-board functionality.
The figure below shows the assembly drawing of the ATmega328P Xplained Mini to help the identification of
components.
Figure 4-1. ATmega328P Xplained Mini Assembly Drawing
