Table of Mainboard Components
Component
AGP1
ATX1
BT1
CPUFAN1
CD1
CD2
CNR1
CPU Socket
DIMM1 ~ DIMM2
FDD1
IDE 1
IDE 2
J1
J2
JP1
JP3~JP6
JP9
JP10
LED1
LSJ1
PANEL1
PCI1~PCI3
PWRFAN1
SIR1
SJ1
USB2
WOL1
WOM1
Note: The red indicator LED1 warns you that the computer is still
powered on and you should not install or uninstall memory modules.
Description
Accelerated Graphics Port
Standard 20-pin ATX power connector
Three volt realtime clock battery
Power connector for CPU cooling fan
Audio connector for CD-ROM/DVD drive
Auxiliary connector for CD-ROM/DVD drive
Communications Networking Riser slot
(CNR supports modem and audio only)
CPU Socket (PGA370)
Two 168-pin DIMM 3.3 volt
Connector for floppy disk drives
Primary IDE channel
Secondary IDE channel
Audio header
External SMI
Clear CMOS jumper
CPU clock ratio jumper
BIOS protection jumper
A/C resume jumper
LED status indicator connector
Single color LED header
Front panel connectors
Three 32-bit PCI slots
Power connector for case cooling fan
SIR connector for infrared
Single color LED header
Connector for USB port
Connector for LAN wake up
Connector for modem wake up
