Model Number
DFB30CCBL-1
1.
Place the barrier screen on the front of the cast iron
ireplace. The brackets will engage the casting opening
between the glass and the cast iron frame. See Figure 1.
2.
Place one side of the barrier screen clips into the front
casting opening with the bottom clip placed on top of the
lower hinge protrusion.
41397-0-1119
INSTALLATION INSTRUCTIONS
FIREPLACE BARRIER FRAMES:
Fits DV Cast Iron Stove Models
DVP30CC(30,70) Series
3.
After engaging the clips with one side of the opening, pivot
the other side of the barrier screen inward until it snaps into
position.
Figure 1
GAS-FIRED
Page 1
Advertisement
Table of Contents
Related Manuals for Empire Comfort Systems DFB30CCBL-1
Summary of Contents for Empire Comfort Systems DFB30CCBL-1
- Page 1 INSTALLATION INSTRUCTIONS FIREPLACE BARRIER FRAMES: Model Number Fits DV Cast Iron Stove Models DFB30CCBL-1 DVP30CC(30,70) Series Place the barrier screen on the front of the cast iron After engaging the clips with one side of the opening, pivot ireplace. The brackets will engage the casting opening the other side of the barrier screen inward until it snaps into between the glass and the cast iron frame.
- Page 2 CHARPENTE DE CADRES D’ÉCRAN POUR FOYER : Numéro de modèle Pour les modèles de poêle en fonte à ventilation directe DFB30CCBL-1 Séries DVP30CC(30,70) Placer l’écran de protection à l’avant du foyer en fonte. Les Après avoir enclenché les attaches d’un côté de l’ouverture, pattes s’enclenchent dans l’ouverture en fonte entre le verre...
