INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
Log sets comply with 4.96 US. State or local codes may
Check your state or local codes.
WARNING: If not installed, operated and maintained
in accordance with the manufacturer's instructions,
this product could expose you to substances in fuel
or from fuel combustion which can cause death or
serious illness.
-
OUTDOOR LOG SET
OUTDOOR GAS FIREPLACES
MODELS
OLX24WR-1
OLX30WR-1
Installer:
Leave this manual with the appliance.
Consumer: Retain this manual for future reference.
FOR
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Empire Comfort Systems OLX24WR-1
Summary of Contents for Empire Comfort Systems OLX24WR-1
- Page 1 INSTALLATION INSTRUCTIONS AND OWNER'S MANUAL Comfort Systems OUTDOOR LOG SET OUTDOOR GAS FIREPLACES MODELS OLX24WR-1 OLX30WR-1 WARNING: If the information in these instructions Installer: Leave this manual with the appliance. Consumer: Retain this manual for future reference. result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Section Page Important Installation Guidelines ............. 3 General Information ................3 Parts List & Parts View ................4 Master Parts Distributor List..............5 How To Order Repair Parts..............5 Log Placement ..................6 - 14 Appliance Service History ..............15 Page 2 28563-1-0511... -
Page 3: Important Installation Guidelines
IMPORTANT INSTALLATION GUIDELINES Proper Log Placement Make Owners Aware of Proper Log Set Operation Log placement is critical to proper burner performance. Logs Properly installed and properly maintained log sets do not must be correctly positioned onto the burner. The photos in deposit soot on the logs. -
Page 4: Parts List & Parts View
Attention: When ordering parts, it is very important that part number and description of part coincide. OLX-24WR-1 INDEX INDEX TOP VIEW FRONT VIEW Part No. Index No. Description OLX24WR-1 OLX30WR-1 R10800 R10800 Ember Bed Right R10866 R10799 Ember Bed Left R10942... -
Page 5: Master Parts Distributor List
For the current list, please click on the Master Parts button at www.empirecomfort.com. Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original Equipment repair parts for Heaters, Grills, and Fireplaces manufactured by Empire Comfort Systems Inc. Dey Distributing... -
Page 6: Log Placement
LOG PLACEMENT Before you begin: Do not, handle these logs with your bare hands! Always wear gloves to prevent skin irritation. After handling logs, wash your hands gently with soap and water. All Logs The positioning of the logs is critical to the safe and clean operation of this heater. Sooting and other problems may result if Refer to Figure 1 for the following warning. - Page 7 LOG PLACEMENT 1. Place Ember Bed Right (A) onto pins 1 and 2 and slide the edge of log under the grate bar. FRONT VIEW TOP VIEW 28563-1-0511 Page 7...
- Page 8 LOG PLACEMENT 2. Place Ember Bed Left (B) between the grate bar and tucked next to Ember Bed Right (A). Do not cover any ports. FRONT VIEW TOP VIEW Page 8 28563-1-0511...
- Page 9 LOG PLACEMENT 3. Place Ember Chunk (C) under the grate bar and around the Left Front Flame Standoff. Ember Chunk (C) will touch Ember Bed Left (B). FRONT VIEW TOP VIEW 28563-1-0511 Page 9...
- Page 10 LOG PLACEMENT 4. Place Right Front Log (D) onto pins 3, 4 and 5, behind Ember Bed Right (A) and around Right Front Flame Standoff. FRONT VIEW TOP VIEW Page 10 28563-1-0511...
- Page 11 LOG PLACEMENT 5. Place Left Front Log (E) onto pins 6 and 7 behind Ember Bed Left (B) and Ember Chunk (C). The right front portion of Left Front Log (E) rests on the back left side of Right Front Log (D). FRONT VIEW TOP VIEW 28563-1-0511...
- Page 12 LOG PLACEMENT 6. Place Right Rear Log (F) onto pins 8 and 9. Right Rear Log (F) "connects" with Left Front Log (E) to give the appearance of one single log. FRONT VIEW TOP VIEW Page 12 28563-1-0511...
- Page 13 LOG PLACEMENT 7. Place Left Rear Log (G) onto pin 10 and log support shelf. FRONT VIEW TOP VIEW 28563-1-0511 Page 13...
-
Page 14: Log Placement
LOG PLACEMENT 8. Place Top Log (H) onto grooves in Left Rear Log (G) and Left Front Log (E). The "thumb" on the Top Log (H) will point to the right. FRONT VIEW TOP VIEW Page 14 28563-1-0511... -
Page 15: Appliance Service History
APPLIANCE SERVICE HISTORY Date Dealer Name Service Technician Name Service Performed/Notes 28563-1-0511 Page 15... - Page 16 Empire Comfort Systems Inc. 918 Freeburg Ave. Belleville, IL 62220 If you have a general question about our products, please e-mail us at info@empirecomfort.com. If you have a service or repair question, please contact your dealer. Comfort Systems www.empirecomfort.com Page 16...
